Dual Channel PM 2.5/10 Dust Sampler

Name: Dual Channel PM 2.5/10 Dust Sampler
Brand: EnvMart
SKU: AABTX
Availability: InStock

₹1

Enquire Now

Tax included

Quantity

Specifications

Display	20x4 LCD display showing parameters in real time with switchable option for viewing PM2.5 or PM10 parameters Flow Rate in LPM Volumetric Flow in m3 Barometric Pressure in mmHg Ambient Temperature in Deg C Filter Temperature in Deg C
Calibration	Fluid Control Research Institute\| Palakkad\| Kerala
Filter Media	Designed for accommodating any filter paper having size 47mm (for PM10) or 46.2mm (for PM2.5)
Temperature Sensors	One Ambient Temperature & 2 Filter Temperatures (for PM2.5 and PM10) Range - 5C to 50C With a Resolution of 0.10C.
Clock / Timer System	Programmable Real Time control system with Automatic start & stop & Digital Display of Date & Time & Time of Sampling. Accuracy 2 min / month.
Output Terminal	RS-232C for connection to PC and USB Flash Drive (Optional)
PM 2.5 Inlet	USEPA based PM10 Inlet coupled with USEPA based PM 2.5 WINS Impactor for separation of coarse particles.
Flow Rate Meter & Volume Totaliser	Dual channel Flow display for PM2.5 and PM10 in LPM with a Resolution of 0.01 LPM under actual operating conditions. Cumulative Volume totalization after every 30 seconds available on Display with resolution of 0.01m3
Flow Control as per FRM sampler guidelines of USEPA	Flow rate for both channels (PM2.5 & 10) independently maintained Constant @ 16.67 LPM with 2% Accuracy throughout Sampling Period using indigenously developed Microprocessor Based Digital Dual Flow Controller.
PM 10 Inlet	USEPA based Omni-directional ambient particle inlet with 10 separation assembly & sample transport tube.

Key Features

Bulk Quantities Available

Reference AABTX Category Dust Sampler

Product Details

Dual Channel PM 2.5/10 Dust Sampler Instrumex Dual Channel Ambient FineDust Sampler, Model No. IPM-FDS-2510 For Simultaneous Measurement Of PM2.5And PM10 in Ambient Air.Microprocessor-Based Model with Data Logging for all 5 parameters.DesignedAs Per USEPA & CPCB Guide Lines
