Single Beam Atomic Absorption Spectrophotometer 190-900nm

Name: Single Beam Atomic Absorption Spectrophotometer 190-900nm
Brand: EnvMart
SKU: AAFSL
Availability: InStock

Enquire Now

Quantity

Reference AAFSL Category Atomic Absorption Spectroscopy

shubh-scientific-atomic-absorption-spectrophotometer

5/5

Free Delivery in India | Lowest Global Shipping Charges

Atomic Absorption Spectroscopy

In Stock

Compare

Single Beam Atomic Absorption Spectrophotometer 190-900nm

Reference AAFSL Category Atomic Absorption Spectroscopy

Specifications

Brand	Shamboo scientific
Resolution	Min 3 lines (279.5 & 279.8 peak and Valley )
Bandwidth	0.1\|0.2\|0.4\|1nm(4 step auto switching)
Instrument Type	Single Beam Reflection Achromatic Optics System
Photometric Range	0-125%\| -0.1-3.00A
Detection limit	(Cu) 0.004 g/ml max
Safety measures	Flame fuel gas\| power assisted gas abnormal pressure protection Gas Leak check\| prevention of gas release when flame dies out\| prevention of flashback through pressure monitoring.
Working Temperature range	10~300C
Concentration	standard curve\| standard addition\| interpolation
Spray Chamber	Anticorrosion material
Gas Control	Automatic control & optimization flow/pressure)
Monochromator	Aberration Corrected Czerny-Turner
Dispersion elements	Grating system 1200 line/mm characterization area 40mm 2 Scintillation wavelength 250nm
WL Range	190-900
WL Accuracy	0.2
WL Repeatability	0.1 nm max
HCL housing	Standard 4 lamp turret .( 1for measurement \| 3 in warm-up mode) Option -6 Lamp / 8 Lamp Turret .
Static Baseline Drift	(Cu) +-0.003A/30min
Dynamic BaselineDrif	(Cu) +-0.006A/30min
BACKGROUND CORRECTION	High speed self-reversal (BGC-SR) method High speed D2 lamp method (BGC-D2)
Characteristic Concentration	(Cu) 0.025 g/ml max
Burner	Air cooled Titanium
Times of repetitive	Measurement 1-30 times\| Average Value of A&C
Dimension & Weight (Flame)	700420550 mm\| 103 kg(approx.)
Power (Main unit with(Flame)	AC 220 V 10%\| 50 Hz without sharp fluctuations.
Working Humidity range	40%~85%

Key Features

Advance technology for intelligent stray light measure and correction Original Optical Noise Reduction & Automatic measurement and stray light dynamic detected without any reference materials and incremental cost. It improves instruments optical performance, optical precision, linear range and background correction effectively
Develop internal lamp control technology. It makes normal hallow cathode lamps self-absorption background correction possible without and in?uence to instrument's stability. Meanwhile it will prolong working life of the lamps. Normal hallow cathode lamps are highly economical than special lamps

Product Details

We present a wide range of Quality Equipment required in day-to-dayfunction of aChemical Laboratory to Advanced Instruments used for QualityAssurance/Control and Research.Our Atomic Absorption Spectrophotometer offers a State-of-the-arttechnology bundled with manyfeatures as a complete economical

Original''Hg lamp-regent'' gradient measurement. we established an exact mathematical model. to estimate single beam linear and balancespeci?cation. This technology provided a fast and economic method for instrument self testing system. It also established a brand new method to improve instrument's detection Performance.
Original''Hg lamp-regent'' gradient measurement. we established an exact mathematical model to estimate single beam linear and balancespeci?cation. This technology provided a fast and economic method for instrument self testing system. It also established a brand new method to improve instrument's detection Performance
