Explosion proof Wind speed & Direction Meter WS-E10

Name: Explosion proof Wind speed & Direction Meter WS-E10
Brand: EnvMart
SKU: AABJX
Price: 2548 USD
Availability: InStock

$3,615

$2,548 Save $1,067

Quantity

Reference AABJX Category Anemometer

ws-e10-explosion-proof-wind-speed-meter-and-wsd-e11-explosion-proof-wind-speed-direction-meter

5/5

Free Delivery in India | Lowest Global Shipping Charges

Anemometer

In Stock

Compare

Explosion proof Wind speed & Direction Meter WS-E10

Reference AABJX Category Anemometer

Specifications

Wind Speed Measurement Range	0.350 m/s
Wind Speed Accuracy	+/- 3 %
Operating voltage	12...24 V DC
Mounting	Self-Leveling Mounting Bracket
Temperature Resolution	0.5 C
ATEX Explosion-proof Level	EX II 2 G EX ib IIB T4
Wind Speed Resolution	0.1 m/s
Temperature Measurement Range	-3055C
Data transmission	every 2 seconds
Measurement interval	2 seconds
Transmission frequency	868 MHz/ +10 dBm(standard)\| 908 MHz\| 922 MHz (customizable)
Bluetooth	Optional. Range up to 40m
Audible Alarm	85...90 dB
Units of Measurement	m/s\| km/h\| knots\| mph\| Bf
Wind Direction Measurement Range	0-360\| no blank sector\| contactless magnetic measuring principle
Dimensions - Sensor	height 210 mm\| diameter ( cup to cup ) 120mm
Dimensions - Receiver	150 x 80 x 55 mm
Antenna input (receiver)	50 ohm\| SMA connector
Battery Sensor	3.6V AA Lithium battery\| Type LS14500EX\| Brand SAFT
Relay Contacts Output	4 x relays\| 2 A / 24 V
4-20 mA outputs	4 mAEqual to 0 m/s\| 20 mAEqual to 50 m/s (programmable)

Key Features

Certified as EX II 2 G EX ib IIB T4
Monitor wind condition in hazardous area
IP67 Water-proof. Withstands harsh environments
Smartphone connectivity via bluetooth and using Windsmart iOS/Android App
Long wireless transmission range. Up to 400m/1300m(XB model only) (2000m with additional external antenna)

Product Details

Introduction- Scarlet Long Range Wireless Explosion Proof Anemometer Series provide two reliable solutions for hazardous area, WS-E10( Explosion-proof Wind speed meter) and WSD-E11(Explosion proof wind speed+direction meter). Both adopt state-of-art wireless technology and obtain ATEX certification. Scarlet WS-E10/WSD-E11 with high-end design and intrinsically safe feature, make it the ultimate solution to improve worksite safety.Unlike the existing explosion proof anemometers in the market, Scarlet WS-E10/WSD-E11 stands out for its wireless technology. Operators can monitor the wind condition in safe distance without cable connection.Integration with your own safety system is also feasible via 4-20mA industrial output. Optional Bluetooth connectivity allows users to monitor wind condition in real time on their smartphones by using Scarlet Winds mart App.With all these unique features, Scarlet aims to improve operation safety in all kinds of harsh environment.Functions-Real time wind speed and directionBar graph of wind gust in the last 2 minutesTemperature4 programmable contact relay outputs4-20 mA industrial outputs, allows external devices connectivity8 hours of wind speed data on history graphMultiple display units connect to one sensor, synchronized monitoringApplication Area-Offshore/onshore platform, Oil & gas industry, Mining industry, Construction.
