KYOCERA AVX 22 nF Multilayer Ceramic Capacitor 100V DC ±10% Through Hole Solder SR201C223KAR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 100V dc |
| Brand | KYOCERA AVX |
| Height | 5.08mm |
| Length | 5.08mm |
| Model | SR201C223KAR |
| Packaging | Tape & Reel |
| Width | 3.18mm |
| Mount Type | Through Hole |
| Series | SR |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -55°C |
| Lead Diameter | 0.51mm |
| Dielectric | X7R |
| Lead Spacing | 2.5mm |
Key Features
- Features X7R dielectric for stable performance over a wide temperature range.
- Rated for a maximum operating temperature of 125°C ensuring reliability in demanding environments.
- Compact dimensions of 5.08mm length, 5.08mm height, and 3.18mm width facilitate easy PCB integration.
- Lead spacing of 2.5mm with a lead diameter of 0.51mm supports robust through-hole mounting.
- Home/Electronic Components, Power & Connectors/Passive Components/Capacitors/MLCCs - Multilayer Ceramic CapacitorsKYOCERA AVX 22 nF Multilayer Ceramic Capacitor, 100V dc, ±10 %, Through Hole SolderRS Stock No.: 537-3690Brand: KYOCERA AVXMan
- Voltages range from 50 V to 500 V.Temperature range up to 125°C.
- Home/Electronic Components, Power & Connectors/Passive Components/Capacitors/MLCCs - Multilayer Ceramic Capacitors
- KYOCERA AVX 22 nF Multilayer Ceramic Capacitor, 100V dc, ±10 %, Through Hole SolderRS Stock No.: 537-3690Brand: KYOCERA AVXManufacturers Part No.: SR201C223KAR
Product Description
KYOCERA AVX SR201C223KAR Multilayer Ceramic Capacitor is a through-hole solder type passive electronic component rated at 22 nF capacitance and 100V DC voltage. It employs X7R dielectric material suitable for applications requiring stable capacitance over temperature variations from -55°C to 125°C. With a tolerance of ±10%, this capacitor ensures precise performance fitting commodity applications.
This model measures 5.08mm in height and length, with a width of 3.18mm, featuring leads spaced 2.5mm apart with a diameter of 0.51mm, optimized for wave soldering processes. It offers excellent thermal shock and vibration resistance, making it reliable for industrial, automotive, and consumer electronic circuits.
The SR series by AVX is known for its robustness and compliance with major standards including ANSI/ESD S20.20:2014, RoHS Directive, and BS EN 61340-5-1:2007, supporting safe electrostatic discharge (ESD) threats mitigation and environmental sustainability.
Features X7R dielectric for stable performance over a wide temperature range. Rated for a maximum operating temperature of 125°C ensuring reliability in demanding environments. Compact dimensions of 5.08mm length, 5.08mm height, and 3.18mm width facilitate easy PCB integration.
Lead spacing of 2.5mm with a lead diameter of 0.51mm supports robust through-hole mounting. Compliant with ANSI/ESD S20.20:2014, RoHS, and BS EN 61340-5-1:2007 standards. This capacitor is ideal for bypass, decoupling, filtering, sample and hold, and timing circuits in industrial, automotive, and consumer applications.
Discover more Multilayer Ceramic Capacitors and electronic components at EnvMart for your precise manufacturing and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The KYOCERA AVX SR201C223KAR has a capacitance of 22 nF.
This model is rated for a maximum voltage of 100V DC.
It employs X7R dielectric material, which provides stable performance over a wide temperature range.
The capacitor measures 5.08mm in height, 5.08mm in length, and 3.18mm in width.
The lead spacing is 2.5mm with a lead diameter of 0.51mm, suitable for through-hole mounting.
The operating temperature range is from -55°C to 125°C.
It has a tolerance of ±10%.
This model supports through-hole mounting with solder termination.
It complies with ANSI/ESD S20.20:2014, RoHS Directive, and BS EN 61340-5-1:2007 standards.
This capacitor is suitable for bypass, decoupling, filtering, sample and hold, and timing circuits in various applications.
The country of origin for this capacitor is India.
This model is packaged in Tape & Reel format.
