Phoenix Contact IC 2.5/16-STGF-5.08 Series Pluggable Terminal Block, 16-Contact, 5.08 mm Pitch, 12A Current 1825640
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 630V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 12A |
| Length | 19.2mm |
| Model | 1825640 |
| Depth | 15mm |
| Width | 91.4mm |
| Housing Material | Polyamide |
| Series | IC 2.5/16-STGF-5.08 |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 16 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
| PCB connector, nominal current | 12 A, rated voltage (III/2): 320 V, number of positions: 16, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin |
Key Features
- Supports nominal current of 12 amperes for reliable electrical performance.
- Features 16 male contacts arranged in a single row with 5.08 mm pitch spacing.
- Constructed with durable green polyamide housing ensuring insulation and longevity.
- Suitable for wire sizes from 2 mm² to 2.5 mm² or AWG 24 to AWG 12.
- Compact dimensions of 91.4 mm width, 19.2 mm length, and 15 mm depth for space-efficient PCB mounting.
- Equipped with screw connection method with tension sleeve for secure and stable wire termination.
- Designed for straight orientation to simplify integration into electronic assemblies.
Product Description
Phoenix Contact 1825640 is a high-quality pluggable terminal block from the IC 2.5/16-STGF-5.08 series, engineered for industrial electronic applications. This terminal block features 16 contacts arranged in a single row with a 5.08 mm pitch, making it suitable for reliable PCB connections in control cabinets, automation systems, and power distribution setups.
The product is built from green polyamide housing, providing excellent electrical insulation and durability. It supports nominal current ratings of 12 amperes and a rated voltage of up to 630 volts, ensuring safe operation in demanding industrial environments.
Wire connection is achieved via a screw mechanism with a tension sleeve, facilitating secure and vibration-resistant wire terminations. The terminal block accepts wire sizes ranging from 2 mm² to 2.5 mm² (AWG 24 to AWG 12), accommodating a wide variety of wiring needs.
With compact dimensions of 91.4 mm width, 19.2 mm length, and 15 mm depth, this terminal block aids in space-saving PCB designs and equipment assemblies. The straight orientation allows for easy integration into existing layouts.
Supports nominal current of 12 amperes for reliable electrical performance. Features 16 male contacts arranged in a single row with 5.08 mm pitch spacing. Constructed with durable green polyamide housing ensuring insulation and longevity.
Suitable for wire sizes from 2 mm² to 2.5 mm² or AWG 24 to AWG 12. Compact dimensions of 91.4 mm width, 19.2 mm length, and 15 mm depth for space-efficient PCB mounting. Equipped with screw connection method with tension sleeve for secure and stable wire termination.
Rated voltage of 630 volts meeting RoHS compliance and industrial standards. Designed for straight orientation to simplify integration into electronic assemblies.
This Pluggable Terminal Block is ideal for use in industrial automation, manufacturing control systems, electrical equipment, and other commercial electronic applications requiring secure, modular terminal connections. Its compliance with RoHS ensures environmentally responsible manufacturing standards.
Explore more industrial electronic connectors and terminal blocks from Phoenix Contact on EnvMart for quality-assured components engineered to meet your application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a nominal current rating of 12 amperes, ensuring reliable electrical performance in various applications.
The rated voltage for this model is up to 630 volts, making it suitable for demanding industrial environments.
It has compact dimensions of 91.4 mm in width, 19.2 mm in length, and 15 mm in depth, facilitating space-efficient PCB mounting.
This terminal block is suitable for wire sizes ranging from 2 mm² to 2.5 mm² or AWG 24 to AWG 12.
The wire connection is achieved via a screw mechanism with a tension sleeve, providing secure and stable wire terminations.
The contacts are arranged with a pitch spacing of 5.08 mm, allowing for effective PCB connections.
The housing is constructed from durable green polyamide, ensuring insulation and longevity.
It features 16 male contacts arranged in a single row, designed for modular connections.
This model is designed for straight orientation, simplifying integration into electronic assemblies.
Yes, it meets RoHS compliance, ensuring environmentally responsible manufacturing standards.
The country of origin for this terminal block is Germany, indicating its manufacturing location.
It is ideal for use in industrial automation, manufacturing control systems, and power distribution setups that require secure terminal connections.
