Festo Pneumatic Clamp , Single-Acting with Diaphragm, 4 mm Stroke, 15x40 mm Clamping Area, 2 - 6 Bar Operating EV-15/40-4

Festo EV-15/40-4 pneumatic clamp is a robust and compact solution designed for firm clamping of workpieces in narrow gaps. This single-acting clamp features a pressure chamber fitted with a diaphragm, making it suitable for clamp strokes against a stop. Its rodless design contributes to its compactness, while the flat profile compensates for uneven surfaces, allowing mounting in any position.

Manufactured from die-cast aluminium free of copper, the clamp offers excellent corrosion resistance and durability, ensuring a long service life even in demanding industrial environments. The clamp is hermetically sealed, making it suitable for use in dusty and harsh conditions.

Technical specifications include a 4 mm stroke length, a clamping area of 15 mm by 40 mm, and operation within a pneumatic pressure range of 2 to 6 bar. The ambient temperature range supported is from -20°C to +40°C. Weighing only 45 grams, this lightweight clamp incorporates a through-hole for easy mounting and an M5 pneumatic connection for seamless integration with pneumatic systems.

The EV Series from Festo represents a pioneering selection of pneumatic clamps and modules tailored for everyday and industrial automation needs. These units come in various configurations, including round and rectangular, with stroke lengths ranging from 3 mm to 5 mm.

The compact, rodless single-action clamp features a diaphragm pressure chamber for firm holding. Suitable for clamp strokes against a mechanical stop with a single-acting reset function. Constructed from die-cast aluminium, free of copper to resist corrosion and extend service life.

Hermetically sealed design allows use in dusty and harsh industrial environments. Operates efficiently within an operating pressure range of 2 bar to 6 bar. Flat design compensates for surface unevenness, enabling mounting in any position.

Ambient operating temperature range is from -20°C to +40°C. Lightweight module weighing 45 grams with through-hole for mounting. Equipped with M5 pneumatic connection for integration with pneumatic systems. Ideal for industrial, manufacturing, automation, and pneumatic air preparation applications.

This pneumatic clamp is well-suited for use in industrial machinery, automation lines, pneumatic air preparation systems, and manufacturing processes requiring precise and reliable workpiece holding in tight or narrow spaces. Its robust construction and dependable operation help improve equipment uptime and process reliability.
