C & K F Series Push Button Switch Interlock Momentary Silicone Elastomer 12.5 mm Cutout DPDT 30V dc 125V ac 103-4001-001

Name: C & K F Series Push Button Switch Interlock Momentary Silicone Elastomer 12.5 mm Cutout DPDT 30V dc 125V ac 103-4001-001
Brand: C & K
SKU: 96362
Price: 12.55 USD
Availability: InStock



Category Push Button Switch Brand C & K Condition New

Specifications

Country of Origin	India
Brand	C & K
Outputs	one side for fitting to the PCB, the other to the wire
Series	F
Maximum Operating Temperature	70°C
Contact Configuration	DPDT
Minimum Operating Temperature	-40°C
Panel Cutout Size	12.5 mm
Terminal type	Solder
Standards/Approvals	UL and CSA, VDE
Switch Operation	Interlock, Momentary, Silicone Elastomer
Actuator Colour	Black
Contact DC Voltage	30V dc
Actuator Style	Button
Switch Contact Current	500mA
Contact AC Voltage	125V ac

Key Features

The switch features a durable black silicone elastomer push button actuator for excellent tactile operation.
It is designed for panel cutouts of 12.5 mm, making it suitable for compact installations.
The DPDT (Double Pole Double Throw) configuration allows versatile wiring options in control circuits.
The switch supports contact voltages of 30V dc and 125V ac with a contact current rating of 500mA.
Terminal connections are via soldering, ensuring reliable and secure electrical contacts.
The actuator style is a momentary push button with interlock functionality to prevent simultaneous actuation.
This switch operates reliably in temperatures ranging from -40°C to 70°C, suitable for varied industrial environments.
Complies with UL, CSA, and VDE standards, ensuring high safety and quality assurance.

Product Description

C & K 103-4001-001 F Series Push Button Switch offers a high-quality interlock and momentary switch solution with a black silicone elastomer actuator. Designed for applications requiring a 12.5 mm panel cutout, it features a DPDT contact configuration supporting 30V dc and 125V ac operation, ideal for various electrical and automation control systems.

The F Series modular pushbuttons provide flexibility in combining switch and pushbutton functions through jumper removal, accommodating many industrial control applications. With a contact current rating of 500mA and solder terminal type, the switch ensures reliable performance and secure connections.

Operating temperature range from -40°C to 70°C enables use in harsh environments. Compliance with UL, CSA, and VDE standards confirm its suitability for industrial and commercial electrical installations. Outputs are designed with dual mounting, allowing one side PCB fitting and the other wired connection, facilitating effortless integration into assemblies.

This switch is particularly suitable for industrial automation, laboratory equipment, HVAC control panels, and machinery control interfaces where momentary interlock switch functionality is needed. The durable silicone elastomer actuator promotes longevity and consistent tactile feedback during operation.

Black silicone elastomer push button actuator ensures durability and responsive action. 12.5 mm panel cutout for compact and precise installation. DPDT contact configuration for versatile circuit applications. Supports 30V dc and 125V ac contact voltages and 500mA current rating.

Solder terminal type offers dependable electrical connections. Interlock and momentary switch operation prevents simultaneous activation. Wide operating temperature range from -40°C to 70°C for industrial environments. Certified to UL, CSA, and VDE standards ensuring compliance and safety.

Modular F series allows combining switch functions through jumper modification. Outputs designed for PCB mounting and wiring flexibility. Explore EnvMart's comprehensive selection of C & K Push Button Switches and related electrical components for your industrial and commercial needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model features a DPDT (Double Pole Double Throw) contact configuration, allowing for versatile wiring options in control circuits.

The maximum operating temperature for this switch is 70°C, making it suitable for various industrial environments.

It requires a panel cutout size of 12.5 mm for proper installation in compact spaces.

This switch supports contact voltages of 30V DC and 125V AC, with a contact current rating of 500mA.

It uses solder terminal connections, ensuring reliable and secure electrical contacts.

The operating temperature range for this switch is from -40°C to 70°C, suitable for harsh environments.

The actuator style is a momentary push button with interlock functionality to prevent simultaneous actuation.

This switch complies with UL, CSA, and VDE standards, ensuring safety and quality assurance.

It features a durable black silicone elastomer actuator, providing excellent tactile operation.

The outputs are designed with dual mounting, allowing one side for PCB fitting and the other for wired connection, facilitating integration into assemblies.

It is particularly suitable for industrial automation, laboratory equipment, HVAC control panels, and machinery control interfaces.

The contact current rating for this switch is 500mA, ensuring reliable performance in various applications.
