HARWIN Datamate L-Tek Series Straight Through Hole PCB Header, 26 Contacts, 2 mm Pitch, 2 Row, Shrouded M80-8532642
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 1.2kV |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 3A |
| Model | M80-8532642 |
| Mount Type | Through Hole |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | Datamate L-Tek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3mm |
Key Features
- Designed with 26 male phosphor bronze contacts plated with gold for enhanced conductivity.
- Housing made from durable Polyphenylene Sulphide material ensuring stability and reliability.
- Features shrouded design with locking latches requiring tooling for connector separation.
- Supports high operating temperatures from -55°C to 125°C for demanding environments.
- Supports 3A current capacity and withstands voltage up to 1.2kV for robust electrical performance.
- Connector system supports board-to-board and wire-to-board applications.
- Tail pins measure 3mm for through hole mounting ensuring secure solder joints.
- High reliability 2.00mm pitch double row PCB header suitable for industrial electronics.
Product Description
HARWIN M80-8532642 is a high-quality PCB Header from the Datamate L-Tek Series featuring a straight through hole configuration with 26 contacts arranged in two rows and a 2 mm pitch. This shrouded connector includes male phosphor bronze contacts plated with gold to ensure excellent conductivity and corrosion resistance. The housing is made from robust Polyphenylene Sulphide material, suitable for demanding industrial applications.
This PCB Header supports current up to 3A and can withstand voltages up to 1.2kV, making it ideal for industrial electronics, power connectors, and board-to-board or wire-to-board connections. The connector is rated for operating temperatures ranging from -55°C to 125°C, ensuring reliable performance in harsh environments.
The connector features locking latches that require tooling for disengagement, ensuring secure connections. Tail pins are 3 mm in length designed for through hole mounting and solder termination types, providing stable mechanical and electrical connections on printed circuit boards.
This product is made in the United Kingdom and is new. It complies with no specific standards or approvals, thus mainly used in industrial and electronic manufacturing applications.
26 male phosphor bronze contacts with gold plating for superior electrical contact. Housing made from Polyphenylene Sulphide for durability and high temperature resistance. Shrouded design with secure locking latch system requiring tooling.
Supports current rating of 3A and voltage up to 1.2kV. Operating temperature range from -55°C up to 125°C. Tail pins length of 3 mm designed for through hole solder termination. Connector system suitable for board-to-board and wire-to-board applications.
Ideal for industrial electronic, power, and PCB connector applications. Explore more high-quality PCB connectors and headers in the Electronics & Electricals category at EnvMart for your industrial, laboratory, and manufacturing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current capacity of 3A.
It can withstand voltages up to 1.2kV.
The operating temperature range is from -55°C to 125°C.
This PCB header features 26 male contacts.
The pitch size of the contacts is 2 mm.
The housing is made from Polyphenylene Sulphide material.
It uses solder termination type for connections.
The tail pins measure 3 mm in length.
It is suitable for board-to-board and wire-to-board applications.
Yes, it features a shrouded design with locking latches that require tooling for disengagement.
This product is made in the United Kingdom.
The contacts are made of phosphor bronze and are plated with gold for enhanced conductivity.
