Bourdon 40 mm G 1/8 Bottom Pressure Gauge 4 bar MAT1-D10.B19

Bourdon MAT1-D10.B19 is a precision 40 mm bottom connection pressure gauge designed to measure pressures up to 4 bar with an accuracy of ±2.5%. This pressure gauge features a robust black painted steel case and a white dial with easy-to-read black graduations and a knife edge aluminium pointer. The G 1/8 bottom connection size allows suitability for diverse fluid power and pneumatic installations.

The gauge conforms to EN 837-1 and PED 97/23/CE standards, ensuring compliance and reliability for industrial use. It has an operating temperature limit of 70°C and is rated IP32 for protective resistance against dust and solid objects.

The cupreous Bourdon tube coupled with a brass connection assembly provides excellent durability and precision. This gauge is well suited for applications including compressed gases, lubricating circuits, hot or cold water networks, and water distribution systems.

Its design supports use in mechanical, fluid power, and industrial contexts where reliable pressure monitoring is critical. The compact 40 mm dial size enhances installation flexibility within confined spaces.

Robust black painted steel case construction for durability. White dial with black graduations and knife edge aluminium pointer for clear visibility. G 1/8 bottom connection for versatile mounting options. Compliance with EN 837-1 and PED 97/23/CE standards.

Rated IP32 for protection against solids and limited dust. Operates effectively with pressures up to 4 bar and temperatures up to 70°C. Constructed with a cupreous metal Bourdon tube and brass connections. Suitable for compressed gases, hydraulic, and pneumatic systems.

Ideal for industrial, laboratory, HVAC, and manufacturing pressure measurement applications. Explore more precision measurement instruments and Pressure Gauges on EnvMart for your industrial and laboratory needs.
