Wurth Elektronik 3460B Series Pluggable Terminal Block, 2 Contacts, 2.5 mm Pitch, 1 Row, Polyamide Housing 691346000002B

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 3460B Series Pluggable Terminal Block, 2 Contacts, 2.5 mm Pitch, 1 Row, Polyamide Housing 691346000002B

Name: Wurth Elektronik 3460B Series Pluggable Terminal Block, 2 Contacts, 2.5 mm Pitch, 1 Row, Polyamide Housing 691346000002B
Brand: Wurth Elektronik
SKU: 90724
Price: 2.25 USD
Availability: InStock



Category Pluggable Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	150V
Brand	Wurth Elektronik
Colour	Black
Orientation	Vertical
Current	6A
Length	6.1mm
Model	691346000002B
Depth	15mm
Width	5mm
Housing Material	Polyamide
Series	3460B
Number of Rows	1
Pitch	2.5mm
Number of Contacts	2
Connector Gender	Male
Minimum Wire Size mm²	0.2mm²
Maximum Wire Size mm²	0.5mm²
Minimum Wire Size AWG	26AWG
Maximum Wire Size AWG	20AWG
Wire Connection Method	Push-in
Insulator Flammability Rating	UL94 V-0

Key Features

Supports 2 contacts for efficient electrical termination.
Designed with a compact 2.5 mm pitch for modern PCB layouts.
Accommodates wire sizes from 0.2 mm² to 0.5 mm² (26 AWG to 20 AWG).
Withstands up to 150 V and 6 A current per contact, ensuring safety in various applications.
Features a vertical, push-in male connector for easy installation and maintenance.
Housing made from polyamide, rated UL94 V-0 for high flame resistance.
Black colour and single-row configuration maximize board space efficiency.
Reliable up to an operating temperature of 105 °C, with excellent insulation properties.

Product Description

The Wurth Elektronik 3460B Series Pluggable Terminal Block, model 691346000002B, is engineered for secure and flexible PCB connections in demanding industrial, electronic, and automation environments. Featuring two contacts and a 2.5 mm pitch, this black, single-row terminal block ensures robust cable retention and straightforward installation, ideal for both prototyping and production applications.

This pluggable male terminal block uses a reliable push-in connection method, allowing easy, tool-free wiring of solid and stranded conductors ranging from 0.2 mm² to 0.5 mm². The compact form factor of 6.1 mm (length) by 5 mm (width) by 15 mm (depth) is suitable for dense PCB layouts and space-sensitive applications. The polyamide housing material provides excellent insulation and is rated to UL94 V-0 for flame resistance, protecting circuits in high-temperature or harsh industrial conditions.

Supports 2 contacts for efficient electrical termination. Designed with a compact 2.5 mm pitch for modern PCB layouts. Accommodates wire sizes from 0.2 mm² to 0.5 mm² (26 AWG to 20 AWG). Withstands up to 150 V and 6 A current per contact, ensuring safety in various applications.

Features a vertical, push-in male connector for easy installation and maintenance. Housing made from polyamide, rated UL94 V-0 for high flame resistance. Black colour and single-row configuration maximize board space efficiency.

Reliable up to an operating temperature of 105 °C, with excellent insulation properties.

Ideal for use in industrial automation controls, electronic assemblies, PLCs, HVAC systems, and power distribution boards where secure and maintainable PCB wiring is essential. The WR-TBL series design enables quick changes and replacements without PCB damage.

Each package contains one Wurth Elektronik 3460B Series Pluggable Terminal Block, model 691346000002B. Explore more Wurth Elektronik PCB terminal blocks and components within our Electronics & Electricals catalogue on EnvMart.
