RS PRO 2 Output 20 VA Chassis Mount Transformer, 230V AC Primary, 6.3V AC Secondary, Clamp Mount, 504-561

The RS PRO 504-561 Chassis Mount Transformer is an industry-grade isolation transformer engineered for dependable performance and ease of installation. This transformer features a clamp and frame construction, enabling secure chassis mounting across a variety of electronic and electrical systems.

Rated for a 230V AC primary input, the device provides two independent secondary outputs at 6.3V AC, configurable in series or parallel to optimize voltage and current delivery for diverse circuit demands. With a power capacity of 20 VA, it suits both control panel and general equipment applications, ensuring stable isolation and safe energy transfer.

The transformer is constructed using a double-section bobbin and fully shrouded enclosure, offering full varnish impregnation to maximize insulation integrity and minimize heat build-up. Solder tag terminations simplify wiring, and integrated wrap-over clamps ensure fast, tool-friendly mounting to the chassis.

Operating reliably over temperatures from -30°C to 130°C, the RS PRO transformer is tested electrically and for flash resistance, providing assurance of compliance and safety. Compact in form, it occupies only 59mm x 57mm x 50mm and weighs 210 grams, making it suitable for installations where space and weight are critical.

This chassis mount transformer adheres to international standards including ASNZS 61558, CE, IECBSEN 615581, IECBSEN 615586, and RoHS, supporting environmentally responsible designs. Typical use cases include industrial automation controls, laboratory power supplies, electrical equipment isolation, and HVAC panel integration.

A wide operating frequency range (50 - 60 Hz) enables compatibility in both domestic and commercial settings. Its two-hole fixing design facilitates easy assembly, and the robust construction ensures longevity in demanding environments.

Engineers and technicians benefit from RS PRO’s rigorous testing and professional assurance, making this transformer the smart choice for safe and reliable electrical isolation in technical projects.
