Ewellix Makers in Motion Linear Guide Carriage LLTHC 30 A T0 P5, Flanged, 100.4 mm Length, 90 mm Width, 26100 N Dynamic Load
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Ewellix Makers in Motion |
| Model | LLTHC 30 A T0 P5 |
| Series | LLTHC 30 A T0 P5 |
| Static Load Rating | 41900N |
| Dynamic Load Rating | 26100N |
| Carriage Length | 100.4mm |
| Carriage Width | 90mm |
| Carriage Type | Flanged |
Key Features
- Equipped with side and inner seals integrated in the carriage by standard.
- Supports equal load carrying capacity with top rigidity for enhanced performance.
- Features rails with dual reference sides for precise alignment and installation.
- Provides low surface roughness for smooth running on high-quality surfaces.
- Operates with low friction and wear, ensuring extended service life and reliable operation.
- Allows easy installation and adjustment with low maintenance requirements.
- Flanged carriage design with standard height available from size 15 to 45.
- Equipped with 4 larger threads for flexible mounting from top and bottom sides.
Product Description
The Ewellix Makers in Motion LLTHC 30 A T0 P5 Linear Guide Carriage is a premium flanged linear guide block designed for advanced industrial motion systems. This carriage combines robust construction and precise engineering to deliver high dynamic load ratings of up to 26100 N, making it suitable for demanding applications requiring stability and accuracy.
Integrated side and inner seals are included as standard, helping to protect the internal mechanism from contaminants and reduce maintenance requirements. The carriage ensures equal load carrying capacity with top rigidity, making it ideal for environments where consistent load distribution and mechanical strength are vital.
Dual reference sides on the rails enable precise installation and alignment within linear motion systems, ensuring repeatable positioning and operational efficiency. The rail surfaces are manufactured to low roughness specifications, facilitating exceptionally smooth running and minimizing friction and wear. This contributes to the carriage's long service life and reliable performance even at high operating speeds.
Designed for easy installation, the LLTHC 30 A T0 P5 supports flexible mounting from both top and bottom sides through four larger threaded holes. The flanged design further enhances stability and simplifies adjustments for a wider range of supported machine and automation setups.
Available in standard heights across sizes 15 to 45, this model is frequently used in automation, manufacturing, CNC machinery, material handling, robotic systems, precision assembly, laboratory automation, and other sectors where reliable and accurate linear movement is required. The country of origin is Taiwan, reflecting the carriage's manufacturing excellence and adherence to international standards.
Explore Ewellix Makers in Motion's complete range of Linear Guide Blocks in the Mechanical Machinery & Spares category on EnvMart for industrial motion solutions that maximize productivity, precision, and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The dynamic load rating of this linear guide carriage is 26100 N.
The carriage has a length of 100.4 mm and a width of 90 mm.
The static load rating is 41900 N.
The flanged design enhances stability and simplifies adjustments, allowing flexible mounting from both top and bottom sides.
The carriage is equipped with integrated side and inner seals that help protect the internal mechanism from contaminants.
This model is frequently used in automation, manufacturing, CNC machinery, material handling, robotic systems, and precision assembly.
The country of origin for this carriage is Taiwan.
The rail surfaces are manufactured to low roughness specifications, facilitating exceptionally smooth running and minimizing friction and wear.
Dual reference sides enable precise installation and alignment within linear motion systems, ensuring repeatable positioning and operational efficiency.
The design of this carriage allows for low maintenance requirements due to the integrated seals and robust construction.
The carriage is equipped with four larger threaded holes for flexible mounting options.
The series name of this linear guide block is LLTHC 30 A T0 P5.
