Phoenix Contact IC 2.5/8-STGF-5.08 Series Pluggable Terminal Block, 8 Contacts, 5.08 mm Pitch, 1 Row, Polyamide 1825569
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 630V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 12A |
| Length | 19.2mm |
| Model | 1825569 |
| Depth | 15mm |
| Width | 50.76mm |
| Housing Material | Polyamide |
| Series | IC 2.5/8-STGF-5.08 |
| Number of Rows | 1 |
| Contact Surface | Tin |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 8 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 2mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
| PCB connector, nominal current | 12 A, rated voltage (III/2): 320 V, number of positions: 8, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin |
Key Features
- Supports up to 8 contact positions for versatile wiring.
- Features a 5.08 mm pitch for secure and consistent spacing between terminals.
- Polyamide housing provides durability and electrical insulation.
- Accommodates wire sizes from 2 mm² to 2.5 mm², compatible with AWG 24 - 12.
- Screw connection method ensures firm and vibration-resistant wire retention.
- Rated for operation at 12A current and 630V voltage for industrial safety.
- Male connector orientation designed for straight insertion into PCB layouts.
- Green color coding for easy identification and standardization on boards.
Product Description
Phoenix Contact 1825569 IC 2.5/8-STGF-5.08 Series Pluggable Terminal Block is designed for robust and flexible PCB connectivity in industrial and electronics applications. With 8 contact positions arranged in a single row and a pitch of 5.08 mm, it facilitates secure, high-density wiring for power and signal transmission.
Constructed with polyamide housing, this terminal block ensures high durability, insulation, and resistance to mechanical stress. Its male connector type, with a straight orientation, enables straightforward mounting and compatibility with a broad range of circuit boards. The screw connection method coupled with a tension sleeve mechanism promotes dependable wire retention that withstands vibration and mechanical loads.
Supporting a wide conductor range, the block accommodates wire sizes from 2 mm² up to 2.5 mm², including AWG 24 to AWG 12, which is suitable for most industrial control systems, automation panels, and power supply circuits. Rated to handle up to 12A current at voltages up to 630V, it is engineered for reliability in demanding environments.
This pluggable terminal block features green color coding for clear identification and visual distinction during assembly and maintenance. RoHS compliance means it meets the requirements for hazardous substance restrictions, making it suitable for regulated manufacturing and safety-sensitive installations.
Typical uses include PCB interface connections in instrumentation, industrial equipment, building automation, HVAC controls, and laboratory electronics. The compact design (19.2 mm length, 50.76 mm width, and 15 mm depth) makes this terminal block ideal for space-conscious applications without compromising connector performance.
When integrated into PCB assemblies, the Phoenix Contact IC 2.5/8-STGF-5.08 provides efficient, modular wiring and maintenance, allowing quick replacement or reconfiguration for system upgrades or service. Contact surface tin plating assists in preserving signal integrity and corrosion resistance.
Explore more Phoenix Contact pluggable Terminal Blocks and accessories in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for operation at 12A current and 630V voltage, suitable for industrial applications.
The contact pitch for this model is 5.08 mm, allowing for secure and consistent spacing between terminals.
It accommodates wire sizes from 2 mm² to 2.5 mm², which corresponds to AWG 24 to AWG 12.
This terminal block features 8 contact positions, arranged in a single row for high-density wiring.
It utilizes a screw connection method, which ensures firm and vibration-resistant wire retention.
The dimensions are 19.2 mm in length, 50.76 mm in width, and 15 mm in depth.
The housing is constructed from polyamide, providing durability and electrical insulation.
The connector orientation is straight, designed for easy insertion into PCB layouts.
Yes, it is RoHS compliant, meeting the requirements for hazardous substance restrictions.
It features green color coding for easy identification and standardization on boards.
Typical uses include PCB interface connections in instrumentation, industrial equipment, building automation, and HVAC controls.
The contact surface is tin plated, which helps preserve signal integrity and corrosion resistance.
