EMERSON ? ASCO Pneumatic Solenoid Valve 5/2 G 520 Series, 1/8 in Port, 24V AC, 8 bar, Manifold Mount, Anodised 52000002
Specifications
| Country of Origin | Poland |
|---|---|
| Voltage | 24V ac |
| Brand | EMERSON ? ASCO |
| Body Material | Anodised Aluminium |
| Maximum Operating Pressure | 8 bar |
| Height | 54.5mm |
| Length | 114mm |
| Model | 52000002 |
| Width | 18mm |
| Mount Type | Manifold |
| Series | 520 |
| Number Of Ports | 5 |
| Maximum Operating Temperature | 50°C |
| Port Type | Push-in |
| Port Size | 1/8 in |
| Seal Material | Nitrile Rubber (NBR) |
| Minimum Operating Temperature | 5°C |
| Actuation Type | Solenoid |
| Maximum Flow Rate | 600L/min |
| Standards/Approvals | RoHS |
| Connection Thread Standard | G |
| Mount Pattern | DIN |
| Minimum Pilot Pressure | 1.5bar |
| Valve Function | 5/2 |
| Electrical Connection Type | Plug Connector |
| Available in 3 different sizes | M5, G1/8" or G1/4" |
Key Features
- 5/2-way pneumatic solenoid valve for double-acting actuator control.
- 1/8 inch push-in port with G thread standard for versatile system integration.
- Operates at 24V AC, supporting industrial automation requirements.
- Anodised aluminium body with Nitrile Rubber (NBR) seal for durability and leak resistance.
- Maximum operating pressure of 8 bar and flow rate up to 600 L/min.
- Suitable for manifold mounting with DIN configuration.
- Plug connector type ensures secure and quick electrical connections.
- Supports operating temperature range from 5°C to 50°C.
Product Description
The EMERSON ASCO 52000002 Pneumatic Solenoid Valve is a high-performance 5/2-way valve engineered for demanding industrial and automation applications requiring reliable directional control of air flow. Designed for integration in complex pneumatic circuits, it is ideal for switching double-acting actuators and is commonly used in manufacturing lines, material handling systems, and packaging equipment.
This model features a 1/8 inch push-in port with G thread standards, ensuring compatibility with a wide range of pneumatic fittings. The solenoid is actuated by a 24V AC voltage supply, delivering quick and consistent switching response, which is vital for automated process control.
The valve body is crafted from anodised aluminium, providing excellent protection against corrosion and mechanical wear in harsh industrial settings. Nitrile Rubber (NBR) sealing elements are used for robust leak prevention as well as enhanced resistance to air and most industrial lubricants. It supports a maximum operating pressure of 8 bar and offers a high flow capacity up to 600 L/min, making it suitable for both high-speed and high-load operations.
The EMERSON ASCO 52000002 can be mounted via a manifold with a DIN-compliant pattern, simplifying the installation and maintenance process in modular pneumatic systems. Its compact size, with dimensions of 114 mm length, 54.5 mm height, and 18 mm width, allows seamless integration into modern control panels and equipment racks.
A plug connector electrical interface ensures safe, secure, and rapid electrical connections. The valve is certified RoHS compliant and its assembly supports a broad temperature range from 5°C to 50°C, ensuring operational stability under varied environmental conditions.
This solenoid valve is part of the EMERSON ASCO 520 Series, known for monostable, bistable, closed, or open centre configurations, and is fully compatible with modular manifolds for flexible system expansion. Its use is prevalent in industrial automation, pneumatic tool systems, assembly and conveyance lines, and wherever precise and reliable pneumatic actuation is required.
Explore more pneumatic control solutions by browsing the Solenoid Valves category, or discover the full range of EMERSON ASCO products for industrial pneumatic automation.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 8 bar.
This solenoid valve operates at a voltage of 24V AC.
It has a maximum flow rate of 600 L/min.
The dimensions of this solenoid valve are 114 mm in length, 54.5 mm in height, and 18 mm in width.
This model supports manifold mounting with a DIN configuration.
The body is made of anodised aluminium, and it features Nitrile Rubber (NBR) seals.
It supports an operating temperature range from 5°C to 50°C.
It features a plug connector type for secure and quick electrical connections.
The valve has a 1/8 inch push-in port with G thread standards.
This model functions as a 5/2-way valve, suitable for controlling double-acting actuators.
Yes, it is certified RoHS compliant.
This solenoid valve is available in three different sizes: M5, G1/8", or G1/4".
