RIGOL MC3534 Multifunction Module
Specifications
| Country of Origin | India |
|---|---|
| Brand | Rigol |
| Operating Temperature | 0 to 55 °C |
| Model | MC3534 |
| Temperature Coefficient | ±0.015% + 1 mV/°C |
| Max Output Current | 10 mA |
| Terminal Block | M3TB34 |
| Voltage Resolution | 1 MV |
| Product Condition | New |
| MPN | MC3534 |
| Output Voltage Range | ±12 V |
| Digital I/O Ports | 4 × 8-bit |
| Totalizer Inputs | 4 |
| Analog Voltage Outputs | 4 |
| DAC Accuracy | ±0.25% + 20 mV |
| Totalizer Max Frequency | 10 MHz |
Key Features
Rigol MC3534 Multifunction Control Module provides integrated automation capabilities for advanced laboratory, industrial, and process test systems.
- Features 4 × 8-bit digital input/output ports for flexible control and data acquisition.
- Equipped with 4 high-speed totalizer inputs for counting and process applications.
- Includes 4 analog voltage outputs with a bipolar range of ±12 V and 1 mV resolution.
- Maximum DAC output current capacity is 10 mA, ensuring reliable analog signal control.
- Offers high DAC accuracy of ±0.25% + 20 mV for precise voltage output.
- Temperature coefficient is ±0.015% + 1 mV /℃ for stable performance across the 0℃ to 55℃ operating range.
- Suitable for automation control, test system integration, and process monitoring applications.
- Accepts terminal block M3TB34 for easy installation and connectivity.
- Totalizer inputs support frequencies up to 10 MHz, ideal for rapid event counting.
- Compact module designed for demanding laboratory and industrial environments.
Product Description
Rigol MC3534 Multifunction Control Module is designed for advanced laboratory, automation, and industrial testing environments, featuring a compact integration of digital input/output, totalizer inputs, and analog voltage outputs for versatile process control.
The MC3534 is equipped with 4 × 8-bit digital I/O ports, 4 totalizer inputs (supporting frequencies up to 10 MHz), and 4 analog voltage outputs capable of ±12 V with fine 1 mV resolution and up to 10 mA output current. The module provides high DAC accuracy of ±0.25% + 20 mV and a low temperature coefficient of ±0.015% + 1 mV/°C, ensuring reliable operation in a range of 0℃ to 55℃. Connectivity is enabled via terminal block M3TB34 for efficient installation.
- 4 channels of 8-bit digital I/O enable flexible laboratory and system-level automation.
- Dedicated totalizer inputs allow precise event or pulse counting in high-speed processes.
- High-resolution analog outputs facilitate integration with instrumentation requiring fine voltage control.
- Bipolar analog outputs and low temperature drift support accuracy for scientific and industrial requirements.
- Compact size allows easy implementation in automated test systems, process monitoring, and laboratory automation setups.
Ideal for industries focused on laboratory automation, scientific measurement, factory automation, and process control. The MC3534 streamlines signal management for engineers, scientists, and system integrators.
Explore more laboratory automation system products from Rigol and leading brands on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Rigol MC3534 features 4 × 8-bit digital I/O ports, 4 totalizer inputs supporting frequencies up to 10 MHz, and 4 analog voltage outputs with a bipolar range of ±12 V and 1 mV resolution.
The maximum output current capacity of the MC3534 is 10 mA, ensuring reliable analog signal control.
The MC3534 operates effectively within a temperature range of 0 to 55 °C.
The analog voltage outputs of the MC3534 have a DAC accuracy of ±0.25% + 20 mV, ensuring precise voltage output.
The voltage resolution for the analog outputs of the MC3534 is 1 mV, allowing for fine control.
Yes, the totalizer inputs can support frequencies up to 10 MHz, making them ideal for rapid event counting.
The MC3534 accepts the terminal block M3TB34 for easy installation and connectivity.
Yes, the MC3534 is designed for advanced laboratory automation, industrial testing, and process control applications.
Industries focused on laboratory automation, scientific measurement, factory automation, and process control can benefit from the MC3534.
The temperature coefficient for the MC3534 is ±0.015% + 1 mV/°C, ensuring stable performance across its operating range.
