Kusam Meco Earth Resistance Soil Resistivity Tester KM1320
Specifications
| Country of Origin | India |
|---|---|
| Package Contents | Kusam Meco KM 1320 Earth Resistance Soil Resistivity Tester / Standard Testing Wire 4nos / Simple Testing Wire 2nos / Earth Rods 4pcs / Battery / Manual Software CD / RS232 Communication Cable / Carrying Case. |
| Measurement Range | Earth Resistance 0.00Ω–30.00kΩ Soil Resistivity 0.00Ω–9000kΩ |
| Brand | Kusam Meco |
| Measuring mode | Precise 4-Pole Measurement 3-Pole Measurement Simple 2-Pole Measurement |
| Function | Measurement Of 2/3/4-Pole Earth Resistance Soil Resistivity Earth Voltage AC Voltage |
| Model | KM1320 |
| Measuring rate | Earth Voltage About 3 Times/Sec Earth Resistance And Soil Resistivity About 5 Sec/Time |
| Backlight | Blue Screen Backlight Suitable For Dim Places |
| Display Mode | 4-Digit Super-Large LCD Display Blue Screen Backlight |
| Measuring method | Earth Resistance Rated Current Change-Pole Method Measurement Current 20mA Max Soil Resistivity 4-Pole Measurement Earth Voltage Average Rectification (Between P(S)-ES) |
| Test Frequency | 128Hz/111Hz/105Hz/94Hz(AFC) |
| Line Voltage | Below AC 600V |
| Shift | Earth Resistance 0.00Ω–30.00kΩ Automatic Shift Soil Resistivity 0.00Ω–9000kΩ Automatic Shift |
| Short-Circuit Test Current | AC 20mA Max |
| Open-Circuit Test Current | AC 40V Max |
| Test Voltage Wave | Sine Wave |
| Electrode Distance Range | 1m–100m Adjustable |
| Measuring Indicator | LED Flash Indicator LCD Count Down Display Progress Bar Indicator |
| LCD Frame Dimension | 128×75 mm |
| LCD Window Dimension | 124×67 mm |
| Standard Test Wire | 4 Wires Red 20m Black 20m Yellow 10m Green 10m |
| Simple Test Wire | 2 Wires Red 1.6m Black 1.6m |
| Auxiliary Earthing Rod | 4 Rods Dia10mm×150mm |
Key Features
- Performs 2-, 3-, and 4-pole earth resistance and soil resistivity tests
- Wide measurement range up to 30kΩ and 9000kΩ·m
- Automatic frequency control and range selection
- 300-set data logger with RS232 interface for data export
- Compact 4.5kg design with full accessory kit and 300h battery life
Product Description
Kusam Meco KM1320 Earth Resistance Tester measures soil resistivity and ground resistance with high accuracy. Compact and easy to use, it’s suitable for field surveys and construction testing. The device ensures stable readings and is ideal for verifying grounding efficiency. It supports engineers in power systems, telecom, and industrial infrastructure development, offering durable performance and reliable results for essential grounding measurements.
Available on EnvMart, these Soil Resistivity Testers deliver precise earth resistance analysis. Kusam Meco Instruments guarantee stability and reliability for grounding and environmental testing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Kusam Meco KM1320 measures earth resistance from 0.00Ω to 30.00kΩ and soil resistivity from 0.00Ω to 9000kΩ.
The KM1320 supports precise 4-pole measurement, 3-pole measurement, and simple 2-pole measurement modes.
The measuring rate for earth resistance and soil resistivity is about 5 seconds per measurement, while earth voltage is measured at about 3 times per second.
The KM1320 operates at test frequencies of 128Hz, 111Hz, 105Hz, and 94Hz, utilizing automatic frequency control.
The package includes the Kusam Meco KM1320 Earth Resistance Soil Resistivity Tester, standard testing wires, simple testing wires, earth rods, a battery, a manual software CD, an RS232 communication cable, and a carrying case.
The KM1320 features a 4-digit super-large LCD display with a blue screen backlight, suitable for use in dim environments.
The electrode distance range for the Kusam Meco KM1320 is adjustable from 1 meter to 100 meters.
The maximum open-circuit test current for the Kusam Meco KM1320 is 40V AC.
The LCD frame dimension is 128×75 mm, and the LCD window dimension is 124×67 mm.
The KM1320 can measure earth voltage and AC voltage, with a line voltage rating below AC 600V.
The Kusam Meco KM1320 has a compact design and weighs 4.5 kg, making it portable for field use.
The Kusam Meco KM1320 is manufactured in India.
