Kusam Meco Double Clamp Multi Function Grounding Resistance Tester KM4237ER
Specifications
| Country of Origin | India |
|---|---|
| Package Contents | Instrument / Carry Bag / 4 Grounding Rods / 2 Current Clamps / Software CD / USB Cable / 4 Test Lines / 2 Simple Test Lines / Built-In 6V Battery / Charger / Manual & Certificate |
| Accuracy | Ground Resistance ±(2%+5) / Soil Resistivity ±(2%+5) / DC Resistance ±(2%+5) / Ground Voltage ±(2%+5) / AC Current ±(2%+5) |
| Display | 108 × 65mmLCD |
| Brand | Kusam Meco |
| Dimension | 277.2 × 227.5 × 153 mm |
| Power | DC 6V 4.5Ah Battery |
| Function | Grounding Resistance Tester |
| Model | KM4237ER |
| Temperature | -10 °C~40 °C / Humidity Below 80% RH |
| Weight | 2450 G |
| Short Circuit Current | AC 20 MA Max |
| Overload Protection | AC 280 V 3 Sec |
| Insulation resistance | More Than 20 MΩ (500 V) |
| Data Storage | 500 Sets |
| Storage Temp | -20 °C~60 °C / Humidity Below 70% RH |
| Clamp Size | 101 × 27 × 214 mm |
| Test Frequency | 128 Hz |
| USB interface | Yes / Data Save / Print |
| Pressure Resistance | AC 3700 V Rms |
| Test voltage | AC 28 V Max |
| Line Voltage | Below AC 100 V |
| Measure Time | AC 2 Times/Sec / Ground 2 Times/Sec / Resistivity 7 Sec/Time |
| Electrode Range | 1 M~100 M |
Key Features
- Dual-clamp design enables on-line earth testing without auxiliary rods
- Supports 2-wire, 3-wire, 4-wire, and clamp methods
- Microprocessor-controlled for fast and stable results
- Backlit LCD for clear display in field environments
- Ideal for telecom, power, oil, and industrial site inspections
Product Description
Kusam Meco KM4237ER Ground Resistance Tester is a high-precision double clamp instrument for fast on-line grounding measurement without auxiliary electrodes. It supports 2, 3, 4 wire, and double clamp testing methods. The large LCD with backlight provides real-time data. Ideal for telecom, power, and industrial applications, it ensures quick, accurate, and safe evaluation of grounding systems without system interruption.
Available on EnvMart, these Ground Resistance Testers use a double-clamp design for non-intrusive measurement. Kusam Meco Instruments ensure safe and accurate grounding verification.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Kusam Meco KM4237ER has an accuracy of ±(2%+5) for Ground Resistance, Soil Resistivity, DC Resistance, Ground Voltage, and AC Current.
The dimensions of the Kusam Meco KM4237ER are 277.2 × 227.5 × 153 mm, and it weighs 2450 grams.
The Kusam Meco KM4237ER features a 108 × 65 mm LCD display, which is backlit for visibility in field environments.
The Kusam Meco KM4237ER is powered by a DC 6V 4.5Ah battery.
The Kusam Meco KM4237ER supports 2-wire, 3-wire, 4-wire, and double clamp testing methods for grounding resistance measurement.
The operating temperature range for the Kusam Meco KM4237ER is -10 °C to 40 °C with humidity below 80% RH.
The package contents for the Kusam Meco KM4237ER include the instrument, a carry bag, 4 grounding rods, 2 current clamps, a software CD, USB cable, test lines, a built-in battery, charger, manual, and certificate.
The Kusam Meco KM4237ER can store up to 500 sets of data.
The test frequency for the Kusam Meco KM4237ER is 128 Hz.
The maximum test voltage for the Kusam Meco KM4237ER is AC 28 V.
Yes, the Kusam Meco KM4237ER features overload protection at AC 280 V for 3 seconds.
The short circuit current rating for the Kusam Meco KM4237ER is a maximum of AC 20 mA.
