Kirloskar 15 kW/20 HP 4 Pole 415V 3 Phase IE2 Foot Mounted Induction Motor (RC160ML)
Specifications
| Frequency | 50 Hz5% |
|---|---|
| Type | Induction Motor |
| Voltage (V) | 415V10% |
| Mounting | Foot Mounted |
| Model | EF046 |
| Insulation Class Type | Class F |
| class | B |
| Protection Class | IP55 |
| Ambient Temperature (ºC) | 0-50 ºC |
| Rated Voltage (V) | 415V |
| Cooling | IC 411 |
| Casing | Squirrel Cage |
| Pole | 4 |
| Frame | RC160ML |
| Output Power Rating (kW) | 15 kW |
| Squirrel Cage | IE2 Efficiency |
| Combined Variations | 0.1 |
Key Features
- IE2 level efficiency as per IS 12615 - 2011 and IEC 60034-30
- High starting and pull-up torgues to accelerate the load.
- Robust and shock resistant stator construction with optimally designed ribs for cooling.
- Die-cast aluminum rotors designed to withstand the severe forces encountered during starting.
Product Description
Kirloskar 15 kW /20 HP 415 V 3 phase induction motor is suitable for various applications like industrial, commercial, agricultural etc. The motor has been designed using latest technologies and materials which make it highly efficient and reliable. This motor can be used as a single or multi speed motor.
- Terminal box located at RHS from driving End.
- Large terminal boxes with sufficient electrical clearances and imporved aesthetics.
- Optimum fan design for better cooling & minimum energy consumption.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output power rating of this motor is 15 kW, which is equivalent to 20 HP.
It operates at a rated voltage of 415V with a tolerance of ±10%.
This model is an induction motor, specifically a squirrel cage type with IE2 efficiency.
The motor has a frequency rating of 50 Hz with a tolerance of ±5%.
The insulation class type is Class F, which indicates a specific temperature rating for the motor's insulation.
It has a protection class of IP55, providing a degree of protection against dust and water.
The motor is rated to operate in an ambient temperature range of 0 to 50 ºC.
This model is foot mounted, which allows for easy installation in various applications.
It utilizes IC 411 cooling, which is designed for efficient heat dissipation during operation.
The motor has a 4 pole configuration, which affects its speed and performance characteristics.
It is suitable for various applications including industrial, commercial, and agricultural uses.
The frame of this motor is designated as RC160ML, which provides specific dimensional details relevant to installation.
