Mextech Power Meter BM9900
Specifications
| Country of Origin | India |
|---|---|
| Package Contents | Mextech BM9900 Power Meter / Power Supply cable / Fuses / Instruction Manual |
| Current Range | 10mA – 20 A AC (switch the Range automatically) |
| Frequency range | 45-65 Hz |
| Power Factor Range | 0.001 – 1.000 |
| Voltage Range | 5V – 600V AC(Switch the Range automatically) |
| Brand | Mextech |
| Power Supply | 85 – 265 V AC 50/60Hz / 85 – 265V DC |
| Model | BM9900 |
| Communication Interface | Optional RS232 or 485 |
| Measuring speed | Five Times per second |
| Input Impedance | greater than 1 M ohm / (All Voltages) |
| Basic accuracy | +- (0.4% Read + 0.1 % Range +1 Digit) |
| Power range | 0.1 W – 12 KW |
| Speak Voltage | 700V AC |
| Min. Test Voltage | 5V AC (under 5V / Can be Customized) |
| Speak Current | 26A AC |
| Min. Testing Current | 10mA AC (under 10mA / Can be customized) |
| Compute mode | Watt (W)/ Voltage (V) * Current (A) equal to Power Factor (PF) |
| Volume & Weight | 355mm(L)*223mm(W)*112mm(H) / 1.7kg |
Key Features
- All measurements are Trms
- Automatic Range
- Accuracy : 0.5
- Not affected by external noise
- Support data latching can be set lower and upper alarm function, PASS the light is Green, NG the light is Red, Easy to distinguish.
- Connection: Single Phase
- Display: LED Digital Screen
- Measuring Items: Voltage, Current, Active Power, Power factor, Frequency
- Measuring Form: TRMS
- Optional Accessories: RS232 Cable and Software
Product Description
The Mextech BM9900 Power Meter is a digital device used for measuring power parameters such as active power, reactive power, apparent power, voltage, current, frequency, and power factor in single or three-phase systems. With a high sampling rate and accurate digital processing, it offers reliable performance for energy audits, electrical diagnostics, and industrial system monitoring. It features a large backlit LCD display, true RMS measurement capability, and data logging features. Ideal for utility, HVAC, and energy management professionals, the BM9900 helps identify inefficiencies and optimize electrical systems.
Available on EnvMart, these Clamp Meters are versatile instruments used for measuring current without direct contact. Mextech Clamp Meters offer precision, reliability, and safety, making them ideal for electricians, technicians, and industrial use.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Mextech BM9900 Power Meter has a voltage range of 5V to 600V AC, with automatic range switching.
The current range of the Mextech BM9900 is from 10mA to 20A AC, and it switches the range automatically.
The Mextech BM9900 supports a frequency range of 45 to 65 Hz.
The basic accuracy of the Mextech BM9900 is ±(0.4% Read + 0.1% Range + 1 Digit).
The Mextech BM9900 can measure power factors ranging from 0.001 to 1.000.
The dimensions of the Mextech BM9900 are 355mm (L) x 223mm (W) x 112mm (H), and it weighs 1.7 kg.
The Mextech BM9900 requires a power supply of 85 to 265 V AC at 50/60Hz or 85 to 265V DC.
The Mextech BM9900 has optional communication interfaces of RS232 or RS485.
The package of the Mextech BM9900 includes the power meter, power supply cable, fuses, and an instruction manual.
The Mextech BM9900 measures at a speed of five times per second.
The Mextech BM9900 can measure power in the range of 0.1 W to 12 KW.
The input impedance of the Mextech BM9900 is greater than 1 M ohm for all voltages.
