Optical Emission Spectrometer EOES-A10
Specifications
| Country of Origin | UK |
|---|---|
| Power Consumption | Spark — 750W/Standby — 100W |
| Brand | Generic Brand |
| Power Supply | AC 220V/50 Hz |
| Design | Thermal deformation self-compensation |
| Operating Temperature | 10°C to 35°C / 23±2°C is recommended |
| Storage Temperature | 0°C to 45°C |
| Detector | High-resolution CCD Multi detectors |
| Model | LOES-A10 |
| Wavelength Range | 165 nm to 589 nm |
| Weight | 235 kg |
| Type of Product | Spectrometer |
| Humidity range | 20% to 80% |
| Processor | High-speed data synchronization acquisition |
| Dimension (L × W × H) | 650 x 860 x 1200 mm |
| Ignition Voltage (V) | Greater than 1500 V |
| Optical System Focal Length | 400 nm |
| Degree of Vacuum | Auto control within 6-20 pa |
| Measurable Elements | Fe / Al / Cu / Ni / Ti / Co / Zn / Sn / Mg / Pb etc. |
| Pixel Resolution | 30 µm |
| Grating Line | 2400 l/mm |
| First-Order Spectral Line | 1.2 nm/mm |
| Average Resolution Ratio | 10 nm/pixel |
| Spark Source Type | Digital arc and spark source |
| Spark Frequency | 100 to 1000 Hz |
| Discharge Current | 1 to 400 A |
| Spark Stand Electrode | Tungsten electrode technology |
| Argon Quality | 99.999% / Argon pressure Greater than 4 Mpa |
| Argon Consumption | 5 L/min during spark mode |
Key Features
- Automatic lightroom temperature control
- Spray discharge electrode technology
- Adjustable electrode technology
- Ethernet data transmission interface
- High energy precombustion technology HEPS
- Digital Inspire Illumination System
- Optimizable discharge parameters design
- Unique argon gas supply system
- User-friendly visual analysis software
Product Description
Optical Emission Spectrometer LOES-A10 utilizes full-digital spark optical spectrum technology for efficient analysis. With a wavelength range of 165nm to 589nm, it provides a focal length of 400 nm. Features an optimized vacuum optical chamber design for enhanced performance. Incorporates an excitation light source and employs advanced CCD detectors for detailed detection capabilities. Boasts a high-speed data readout system for analysis. Offers ultra-low detection limits, with stability and repeatability.
Applications:
Optical Emission Spectrometer is ideal for quality control, material brand recognition, and R&D in the metallic manufacturing, processing, and smelting sectors.
Standard Accessories:
- Optical Emission Spectrometer - 1 Set
- Business computer - 1 Set
- Printer - 1 Set
- Tungsten electrode - 1 Pc
- Electrode pressure spring - 1 Pc
- The electrode fixed screw - 2 Pcs
- Electrode brush - 2 Pcs
- Lens holder sealing ring - 2 Pcs
- Lens holder sealing ring - 1 Pc
- Exhaust gas filter core - 1 Pc
- Degreasing cotton - 15g
- Power socket - 1 Pc
- M2 Internal hexagonal wrench - 1 Set
- M4 Internal hexagonal wrench - 1 Set
- Long handle Phillips screwdriver - 1 Pc
- 13-15 fixed wrench - 1 Pc
- Spark machine screw - 4 Pcs
- Fuse - 2 Pcs
- Argon gas pressure-reducing valve - 1 Pc
- Argon gas pipeline - 2 M
- Exhaust pipe - 1 Pc
- Gas bottle - 2 Pcs
- Print paper - 1 Pc
- Spectrometer manual - 1 Set
- 1KV voltage stabilizer - 1 Pc
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The wavelength range of this spectrometer is from 165 nm to 589 nm.
The power consumption is 750W during spark operation and 100W in standby mode.
This model can measure elements such as Fe, Al, Cu, Ni, Ti, Co, Zn, Sn, Mg, and Pb.
The operating temperature range is from 10°C to 35°C, with a recommended temperature of 23±2°C.
This model weighs 235 kg.
The average resolution ratio is 10 nm per pixel.
The humidity range for operation is between 20% to 80%.
The dimensions are 650 mm in length, 860 mm in width, and 1200 mm in height.
It uses a digital arc and spark source for excitation.
The argon consumption is 5 L/min during spark mode.
Included accessories are a business computer, printer, tungsten electrode, electrode pressure spring, and various tools and components for setup.
