Lab Spray Dryer ELSD-A10
Specifications
| Country of Origin | UK |
|---|---|
| Display | 7-inch LCD |
| Brand | Generic Brand |
| Power Supply | 220 V / 50/60 Hz |
| Power | 3500 W |
| Body Material | SUS304 Stainless steel |
| Dimensions | 750 × 650 × 1200 mm |
| Operation Mode | Automatic/Manual |
| Model | LLSD-A10 |
| Weight | 110 kg |
| Heater Power | 3000 W |
| Type of Product | Laboratory Spray Dryer |
| Sound | Less than 60 dB |
| Compressor | Built-in oilless |
| Rated Airflow | 1.5 m³/h |
| Minimum Sample Volume | 30 ml |
| Temperature precision | ±1 °C |
| Compressed Air Pressure | 0.2 to 2 bar |
| Nozzle Jet | 0.7 mm standard (0.5/0.75/1.0/1.5/2.0 mm available) |
| Nozzle Type | Two fluid nozzle |
| Possible Particle Size Range | 1 to 25 µm |
| Mean Residence Time | 1.0 to 1.5 sec |
| Max. Sample Feed | 2000 ml/hr |
| Atomizer Material | SUS 316 Stainless steel |
| Evaporating Capacity (Water) | 1.5 L/hr |
| Max. Input Temperature | 250 °C |
| Compressed Airflow | 32 L/min |
| Spray Gas | 4.2 m²/h / 2-5 bar |
| Spray Chamber Material | Borosilicate Glass |
| Cyclone Separator Material | Borosilicate Glass |
| Receiving Tank Material | Borosilicate Glass |
| Seal of Cylinder | Silicone |
| Thermal Protection | Blower stops when temp Less than 90 °C |
Key Features
- Equipped with a built-in air compressor
- SUS 316 Stainless steel Atomizer
- Automatic/manual operation mode
- Optional Inert loop for organic solvents
- Automatic deblocking feature
Product Description
Lab Spray Dryer LLSD-A10 requires only 30ml of sample for an experiment. Capable of accommodating a maximum of 2000ml/hr sample feed. The chamber is constructed from borosilicate glass, allowing clear observation. Equipped with a 7-inch LCD that displays heat, spray, pump, air pressure, and de-blocker frequency. Our dryer can be upgradable to an organic solvent spray dryer with an inert loop system.
Applications:
Our Lab Spray Dryer is versatile for use in industries such as chemical, food, new energy, medicine, biology, materials, ceramics, energy, textiles, and more.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Lab Spray Dryer LLSD-A10 can accommodate a maximum sample feed of 2000 ml/hr.
The body is made of SUS304 stainless steel, while the spray chamber, cyclone separator, and receiving tank are constructed from borosilicate glass.
It operates on a power supply of 220 V at 50/60 Hz and has a total power consumption of 3500 W.
The temperature precision of this model is ±1 °C.
The Lab Spray Dryer LLSD-A10 features both automatic and manual operation modes, allowing for flexible usage depending on the experiment.
This model requires a minimum sample volume of 30 ml for an experiment.
The possible particle size range is from 1 to 25 µm.
The maximum input temperature for this model is 250 °C.
The sound level of the Lab Spray Dryer LLSD-A10 is less than 60 dB during operation.
The atomizer is made of SUS 316 stainless steel, and it features a two fluid nozzle with a standard jet size of 0.7 mm, with other sizes available.
This model can be upgraded to an organic solvent spray dryer with the addition of an inert loop system.
