ams OSRAM Position Sensor Adapter Board for AS5306 AS5306-TS_EK_AB
Specifications
| Country of Origin | Austria |
|---|---|
| Brand | ams OSRAM |
| Model | AS5306-TS_EK_AB |
| Sensor Technology | Position Sensor |
| For Use With | AS5306 |
| Standards/Approvals | RoHS |
| Kit Classification | Adapter Board |
| Featured Device | AS5306 |
| Kit Name | AS5306-TS_EK_AB |
Key Features
- The adapter board operates with a 5V power supply for efficient performance.
- Quadrature AB outputs connect directly to a microcontroller quadrature counter.
- Equipped with a JP1 connector for simple interfacing.
- Includes four 2.6mm mounting holes for secure installation.
- The design eliminates the need for building custom test fixtures or PCBs.
- Compliant with RoHS standards ensuring environmental safety.
- Manufactured in Austria with high-quality standards.
Product Description
ams OSRAM AS5306-TS_EK_AB Position Sensor Adapter Board for AS5306 is a specialized evaluation tool designed to simplify the testing process of AS5304 and AS5306 linear encoders. This adapter board requires only a 5V power supply to function, making it accessible and convenient for rapid sensor evaluation without constructing custom test setups or printed circuit boards.
The quadrature AB output signals are designed to attach directly to a microcontroller's quadrature counter inputs, facilitating seamless integration with embedded systems and development platforms. The board features a JP1 connector for easy connection and includes four mounting holes sized at 2.6mm, allowing firm and stable installation on various test rigs or development stations.
This adapter board is invaluable for industrial, laboratory, manufacturing, and development environments where accurate position sensing and linear encoder calibration are critical. Compliant with RoHS standards, it ensures adherence to environmental regulations. The product is manufactured in Austria, reflecting ams OSRAM's commitment to quality and reliability in sensor development tools.
The adapter board operates with a 5V power supply for efficient performance. Quadrature AB outputs connect directly to a microcontroller quadrature counter. Equipped with a JP1 connector for simple interfacing. Includes four 2.6mm mounting holes for secure installation.
The design eliminates the need for building custom test fixtures or PCBs. Compliant with RoHS standards ensuring environmental safety. Manufactured in Austria with high-quality standards.
This adapter board is part of the sensor development tools category, suitable for use with AS5306 position sensors and ideal for R&D, prototyping, and sensor calibration processes. Explore more Sensor Development Tools and evaluation boards at EnvMart for industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a 5V power supply for efficient performance.
The quadrature AB output signals connect directly to a microcontroller's quadrature counter inputs, facilitating integration.
The adapter board is equipped with a JP1 connector for simple interfacing.
It includes four mounting holes sized at 2.6mm for secure installation.
This adapter board is manufactured in Austria, reflecting high-quality standards.
It is compliant with RoHS standards, ensuring adherence to environmental regulations.
This unit is suitable for industrial, laboratory, manufacturing, and development environments where accurate position sensing is critical.
The kit classification for this product is an adapter board.
The featured device is the AS5306 position sensor.
The design of this model eliminates the need for building custom test fixtures or PCBs.
