Mersen 20A Bolted Tag Fuse A2 690V AC High Rupture Capacity Offset Tag Fuse R1019260 / BTIA69V20M32

Free Delivery in India | Lowest Global Shipping Charges

Mersen 20A Bolted Tag Fuse A2 690V AC High Rupture Capacity Offset Tag Fuse R1019260 / BTIA69V20M32

Name: Mersen 20A Bolted Tag Fuse A2 690V AC High Rupture Capacity Offset Tag Fuse R1019260 / BTIA69V20M32
Brand: Mersen
SKU: 420727
Price: 20.22 USD
Availability: InStock



Category Tag Fuses Brand Mersen Condition New

Specifications

Country of Origin	India
Voltage	690V ac
Diameter	21.9mm
Brand	Mersen
Height	56.5mm
Length	54.5mm
Model	R1019260 / BTIA69V20M32
Width	21mm
Overall Length	86mm
Current Rating	20A
Series	Offset Tag fuse-links gM 690VAC/460VDC
Standards/Approvals	IEC 60269, EN 60269-2, CE, RoHS, REACH, BS 88
Fuse Size	A2
Fixing Centres	73 mm
Tag Width	9.2mm
Tag Orientation	Offset
Application Category	gM

Key Features

This bolted tag fuse has a current rating of 20A suitable for gM application category.
The fuse size is A2 with a tag width of 9.2 mm and an offset tag orientation.
It complies with IEC 60269, EN 60269-2, CE, RoHS, REACH and BS 88 standards.
Features fixing centres at 73 mm with overall length of 86 mm and diameter of 21.9 mm.
The fuse series is Offset Tag fuse-links gM 690VAC/460VDC suitable for high rupture capacity use.
Manufactured in India and designed for screw-in fuseholders or direct bolting onto busbars or fuse disconnectors.

Product Description

Mersen R1019260 / BTIA69V20M32 bolted tag fuse is a 20A rated fuse designed specifically for AC voltage applications up to 690 volts. It is engineered to provide reliable general purpose protection (gG type) and motor protection (gM type) with excellent current limitation for overloads over a wide range of industrial and commercial electrical installations.

This bolted tag fuse features a fuse size of A2 and a compact design with fixing centres of 73 mm. The tag orientation is offset with a tag width of 9.2 mm, allowing secure placement in fuseholders or direct bolting onto busbars and fuse interruptors or disconnectors.

Compliant with international safety and quality standards including IEC 60269, EN 60269-2, CE, RoHS, REACH, and BS 88, this fuse assures high reliability in circuit protection. The fuse's dimensions include an overall length of 86 mm, a length of 54.5 mm, height of 56.5 mm, a diameter of 21.9 mm, and width of 21 mm, designed to meet diverse industrial application requirements.

This fuse series is characterized by its high rupture capacity, increasing safety in electrical circuits by quickly interrupting fault currents. It is ideal for industrial, manufacturing, electrical automation, and commercial electrical protection applications requiring robust fuse performance.

Manufactured in India, the Mersen bolted tag fuse is a trusted choice for ensuring circuit protection with ease of installation and compliance to rigorous standards. Set contains a single bolted tag fuse rated at 20A and 690V AC, designed to fit securely within standard fuseholders or mounting on busbars.

This tag fuse provides efficient overload and motor protection in electrical circuits. Complies with multiple international standards to ensure safety and reliability. High rupture capacity for fast interruption of fault currents.

Compact size with 73 mm fixing centres and offset tag orientation. Designed for industrial, commercial, and electrical automation applications. Manufactured in India ensuring quality and performance. Explore more from Mersen's range for electrical protection devices and Tag Fuses on EnvMart.
