Cosel Switching Power Supply 24V DC 648W Universal Input 85-264VAC Chassis Mount PCA600F-24-P2
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Cosel |
| Power | 648W |
| Efficiency | 93% |
| Length | 152mm |
| Model | PCA600F-24-P2 |
| Depth | 41mm |
| Gross Weight | 840g |
| Width | 89mm |
| Mount Type | Chassis |
| Series | PCA |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -20°C |
| Rated Input | 85 - 264VAC 1Φ.Rated Output Wattage: 600W.Warranty Period 5-year (Refer to Instruction Manuals).Make sure necessary tests will be carried out on your end equipment with the power supply installed in accordance with any required EMC/EMI regulations |
| Number of outputs | 1 |
| Maximum Input Voltage | 264V ac |
| Standards/Approvals | CE, cULus, RoHS |
| Maximum Output Voltage | 24V dc |
| SMPS Output Current | 27A |
| Minimum Input Voltage | 85V ac |
Key Features
- Operating voltage range from 85 to 264VAC supports wide input compatibility.
- Single output provides a constant current of 27A for stable performance.
- Chassis mount design with slim 41mm profile suitable for compact installations.
- Operating temperature range from -20°C to 70°C ensures reliable operation in diverse environments.
- High efficiency of 93% reduces energy loss and heat generation.
- Equipped with multiple safety and compliance certifications including CE, cULus, and RoHS.
- Supports parallel operation and offers communication-based monitoring features.
- Designed for medical electric equipment compliance with relevant IEC and ANSI standards.
Product Description
Cosel PCA600F-24-P2 is a high-performance switching power supply designed for industrial and medical applications requiring reliable 24V DC power output at 648W. It features a universal input range of 85 to 264VAC single-phase, enabling operation in diverse power environments.
This chassis-mount power supply module measures 152mm in length, 89mm in width, and only 41mm in depth, offering a low-profile 1U height design that facilitates installation within standard equipment racks and enclosures.
With an ambient operating temperature between -20°C and 70°C, this power supply maintains stable output current up to 27A, delivering consistent performance even under varying temperature conditions.
It achieves a high efficiency of 93%, minimizing energy consumption and thermal dissipation. The unit complies with CE, cULus, and RoHS standards, ensuring safety and environmental adherence. It also supports parallel operation and offers monitoring functions via communication interfaces for enhanced control and diagnostics.
Specially designed for medical electrical equipment, it meets ANSI/AAMI ES60601-1, EN60601-1 3rd Edition, and IEC60601-1-2 4th Edition standards, making it suitable for healthcare environments. The output voltage can be varied close to 0V, and constant current regulation is provided for consistent load management.
The power supply includes an auxiliary output and various alarm functions for fault detection. Its universal input voltage and compact build make it ideal for a wide array of industrial, laboratory, HVAC, manufacturing, and commercial power systems.
The Cosel PCA600F-24-P2 is covered by a comprehensive 5-year warranty, offering long-term reliability for critical applications. Users should ensure proper testing under EMC/EMI regulations when integrating this module into their equipment.
Operating voltage range from 85 to 264VAC supports wide input compatibility. Single output with 24V DC at 27A provides stable power. Compact chassis mount design with low 41mm profile. High efficiency rating of 93% reduces energy loss.
Certifications: CE, cULus, RoHS compliant. Suitable for medical equipment, meeting IEC and ANSI standards. Supports parallel operation and communication monitoring. Includes auxiliary output and alarm functions. 5-year warranty for dependable service life.
