SICK Block Inductive Proximity Sensor M20 x 1.5 Thread, NPN Output, 30 V DC, 200mA, 20 mm Detection Distance IQ40-20BNOKK0S
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | SICK |
| Temperature range | - 25 °C to +85 °C |
| Length | 118mm |
| Model | IQ40-20BNOKK0S |
| Depth | 40mm |
| IP Rating | IP67, IP68, IP69K |
| Width | 40mm |
| Mount Type | Flush |
| Housing Material | Plastic |
| Output type | NPN |
| Series | IQ40 |
| Maximum Operating Temperature | 85°C |
| Thread Size | M20 x 1.5 |
| Enclosure Rating | IP 68, IP 69K |
| Minimum Operating Temperature | -25°C |
| Switching Current | 200mA |
| Terminal type | Screw |
| Body Style | Block |
| Maximum dc Voltage | 30V dc |
| Shielding | Unshielded |
| Maximum Switching Frequency | 150Hz |
| Standards/Approvals | UL File No. E348498 |
| Maximum Supply Voltage | 30V |
| Materials Detected | Metal |
| Maximum Detection | 20mm |
| Extended sensing ranges | 20 mm to 40 mm |
| Electrical configuration | DC 3-/4-wire |
Key Features
- Block-style sensor with compact 40 mm width and 118 mm length.
- Flush mountable with push-lock mounting system for easy installation.
- Unshielded sensor head can be rotated in five directions for flexible application.
- High protection ratings IP67, IP68, and IP69K ensure durability in harsh industrial environments.
- Operating temperature range from -25°C to +85°C.
- NPN output type with maximum switching frequency of 150 Hz.
- Plastic housing provides resistant and lightweight construction.
- Suitable for presence detection, positioning, rack identification, and wear detection applications.
Product Description
SICK IQ40-20BNOKK0S block Inductive Proximity Sensor is designed for industrial automation and control gear applications, ensuring precise detection of metal objects up to 20 mm away. The sensor features a robust plastic housing sized 40 mm x 40 mm x 118 mm with flush mount capability and a screw terminal type. It operates at a maximum DC voltage of 30 V and a switching current of 200 mA with an NPN output configuration. The sensor supports DC 3-/4-wire electrical configuration and a switching frequency up to 150 Hz.
This model is highly resistant to harsh environments with enclosure ratings of IP67, IP68, and IP69K, allowing it to withstand dust, water jets, and high-pressure cleaning. Its operating temperature range of -25°C to +85°C and unshielded design with a plastic housing allows use in heavy industrial, manufacturing, and automation processes including presence detection of press tools, positioning in reworking stations, conveyor belt monitoring, and mechanical position sensing.
The innovative push-lock mounting system enables quick installation and replacement without additional tools, and the sensor head can be rotated in five directions, providing installation flexibility. Four corner LEDs provide clear sensor status indication from any viewing angle.
Block style compact design for easy mounting. Extended sensing range from 20 mm to 40 mm for stable detection. Durable plastic housing suitable for severe weather and atmospheric conditions. IP67, IP68, and IP69K ratings deliver waterproof and dustproof protection.
NPN output and 200 mA switching current for reliable electrical interface. Wide temperature range ensures performance in extreme industrial conditions. Push-lock system allows tool-free mounting and quick sensor replacement.
Suitable for applications in industrial automation, manufacturing, material handling, and quality control.
This sensor is manufactured in Malaysia and meets UL standards (UL File No. E348498), guaranteeing quality and safety compliance. It is an ideal choice for those requiring long service life and reliability in demanding environments.
Browse more inductive and proximity sensors at EnvMart to find solutions tailored to your industrial sensor needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum detection distance of this sensor is 20 mm, with extended sensing ranges available from 20 mm to 40 mm for stable detection.
This model features an NPN output type, which is suitable for various industrial applications.
The operating temperature range for this inductive proximity sensor is from -25°C to +85°C.
This sensor has IP67, IP68, and IP69K ratings, providing protection against dust and water ingress, making it suitable for harsh environments.
The maximum switching current for this unit is 200 mA.
It features a flush mount capability with a push-lock mounting system that allows for easy installation and replacement without additional tools.
The thread size for this model is M20 x 1.5.
This inductive proximity sensor is designed to detect metal objects.
The maximum DC voltage for this model is 30 V.
This sensor utilizes a screw terminal type for electrical connections.
The maximum switching frequency for this model is 150 Hz.
This sensor is manufactured in Malaysia.
