Cree LED 5 mm Red Through Hole LED 2.6 V 50 mA 130 mW 30° Viewing Angle C503B-RCS-CW0Z0AA2

Cree LED C503B-RCS-CW0Z0AA2 is a high-performance 5 mm (T-1 3/4) red LED designed for through-hole mounting applications. It operates at a nominal forward voltage of 2.6 V and supports a maximum forward current of 50 mA, delivering a luminous intensity of 12 candela with a dominant wavelength of 630 nm, producing vivid red light.

The LED package features a round shape with clear epoxy lens measuring 8.8 x 5 mm, offering a viewing angle of 30 degrees which is ideal for precise illumination applications. Its optical-grade epoxy resin body provides excellent resistance to temperature variations and moisture, making it suitable for outdoor and harsh environment use.

This model is part of the Cree C503 series, known for high lumen output and reliable stable light output over extended periods, making it well-suited for electronic signs, variable message signs (VMS), advertising displays, amusement devices, and petrol station signage.

Designed to meet RoHS environmental standards, this red LED is manufactured in China and is intended for industrial, commercial, and outdoor electronic applications requiring durable and high-quality illumination.

This LED operates at a forward voltage of 2.6 V and a maximum forward current of 50 mA. Maximum power dissipation of 130 mW ensures robustness in operation. The 5 mm round package and 30° viewing angle provide focused light output.

Optical-grade epoxy resin encasing offers temperature and moisture resistance. Through-hole mount type facilitates easy installation on PCBs. Compliance with RoHS ensures environmentally responsible manufacturing. Applications include electronic signs, motorways signs, variable message signs, advertising, and amusement equipment.
