Siemens Inverter Drive SINAMICS G115D Series 5.5 kW 3 Phase 480V 26.4A 6SL3520-2XA65-5AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-2XA65-5AF0 |
| IP Rating | IP65, IP66 |
| Mount Type | Wall |
| Overall Length | 180mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 5.5kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 26.4A |
| Standards/Approvals | CE, C-Tick (RCM), cUL, EAC, KCC, REACH, UL, SEMI F47 |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
| Compatible Motor Type | AC Motor |
Key Features
- Compatible with SIMOGEAR 2KJ8 geared motors and three phase asynchronous or synchronous motors.
- Supports efficiency classes IE3 and IE4 for high energy efficiency.
- IP65 and IP66 rated for robust protection in harsh environments.
- Integrated safety with STO function and fail-safe digital inputs.
- Modular design enables easy installation on machinery without control cabinets.
- Operates between temperatures of -30°C to 55°C for wide industrial applicability.
- Output frequency capability up to 550 Hz allows flexible motor speed control.
- Wall mount type with compact dimensions (425mm width x 180mm length x 169mm depth).
Product Description
Siemens 6SL3520-2XA65-5AF0 inverter drive from the SINAMICS G115D series provides a powerful, efficient, and robust solution for industrial motor control applications. With a rated power of 5.5 kW and three phase operation at 480V, this drive supports both asynchronous motors and synchronous reluctance motors with IE3 and IE4 efficiency classes respectively.
The drive is suitable for horizontal conveyor systems requiring simple speed control or advanced encoderless vector controls. Its integrated safety features include Safe Torque Off (STO) with fail-safe digital inputs for enhanced operational safety. The modular and user-friendly design minimizes space usage by eliminating the need for control cabinets and reduces cooling requirements.
Featuring an IP65 and IP66 protection rating, this device is designed for harsh industrial environments and wide temperature operation from -30°C to 55°C. The maximum output current is 26.4 A, and the unit offers a flexible output frequency range up to 550 Hz, ensuring adaptability to diverse motor control needs.
Compact wall-mounted dimensions (425 mm width, 180 mm length, and 169 mm depth) make it easy to install in limited spaces. The inverter drive complies with numerous global certifications, including CE, C-Tick (RCM), cUL, EAC, KCC, REACH, UL, and SEMI F47, ensuring compliance with international standards.
The product is made in the United Kingdom and forms part of Siemens' Better World initiative, focusing on energy savings and eco-friendly technology solutions. Compatible with SIMOGEAR 2KJ8 geared motors and asynchronous or synchronous high-efficiency motors.
Supports energy-efficient operation under a wide range of industrial applications. IP65 and IP66 protection for harsh environments. Integrated safety with STL function and safe digital inputs. Compact, modular design ideal for machine installation without a control cabinet.
Wide operating temperature range for varied climates. Flexible output frequency control up to 550 Hz for precision motor speed tuning. Compliance with multiple relevant international standards. Explore EnvMart's catalog for more advanced Inverter Drives and automation components suitable for industrial, manufacturing, HVAC, and conveyor system applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this inverter drive is 5.5 kW.
The maximum output current is 26.4 A.
It has an output frequency capability of up to 550 Hz.
This model is compatible with SIMOGEAR 2KJ8 geared motors and asynchronous or synchronous motors.
The device has IP65 and IP66 ratings, providing robust protection in harsh environments.
It operates between -30°C to 55°C, making it suitable for a wide range of industrial applications.
This unit is designed for wall mounting, which helps save space in installations.
The overall dimensions are 425 mm in width, 180 mm in length, and 169 mm in depth.
It includes an integrated Safe Torque Off (STO) function and fail-safe digital inputs for enhanced operational safety.
It complies with multiple certifications including CE, cUL, EAC, KCC, REACH, UL, and SEMI F47.
The inverter drive is made in the United Kingdom.
It supports efficiency classes IE3 and IE4 for high energy efficiency.
