ABB Tmax XT Molded Case Circuit Breaker 4-Pole 3.2A 690V AC 500V DC Thermal Magnetic Trip 1SDA067564R1 XT2S 160 TMD 3.2A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 3.2A 690V AC 500V DC Thermal Magnetic Trip 1SDA067564R1 XT2S 160 TMD 3.2A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067564R1 XT2S 160 TMD 3.2A FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	3.2A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	4
Standards/Approvals	CE, IEC, REACH, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	3.2 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed for fixed mounting to ensure secure installation.
Equipped with a thermal magnetic tripping mechanism for accurate overload and short circuit protection.
Rated AC voltage of 690 V and DC voltage of 500 V to handle diverse electrical systems.
Compact dimensions with 130 mm height, 120 mm width, and 82.5 mm depth suitable for industrial panels.
Lever type reset actuator allows easy manual operation and reset after tripping.
Conforms to CE, IEC, REACH, and RoHS standards for safety and environmental compliance.
Manufactured in Italy, ensuring high build quality and international standards.

Product Description

ABB 1SDA067564R1 XT2S 160 TMD 3.2A FF Molded Case Circuit Breaker is a high-quality electrical protection device designed for industrial and commercial use. This 4-pole breaker is engineered to provide superior protection against overloads and short circuits through its thermal magnetic tripping mechanism, enhancing safety and reliability in electrical distribution systems.

The device supports a rated alternating current of 3.2 A, designed for systems operating at a rated AC voltage of 690 V and a rated DC voltage of 500 V, making it versatile for various electrical configurations. Its considerable breaking capacity of 85 kA ensures the ability to safely interrupt fault currents without damage, thereby protecting sensitive equipment and personnel.

With fixed mounting and fixed terminal types, installation is secure and stable, suitable for permanent electrical panel setups. The robust lever reset actuator allows for quick and convenient manual reset after trips, minimizing downtime in operations.

Dimensions of 130 mm in height, 120 mm in width, and 82.5 mm in depth provide a compact footprint for space-efficient integration into existing systems. This circuit breaker adheres to international safety and environmental standards, including CE, IEC, REACH, and RoHS, assuring compliance and sustainability.

Manufactured in Italy, ABB guarantees precision engineering and durability, making this breaker ideal for use in industrial automation, electrical distribution, manufacturing facilities, and commercial buildings where dependable circuit protection is critical.

Designed for fixed mounting to ensure secure installation. Equipped with a thermal magnetic tripping mechanism for accurate overload and short circuit protection. Rated AC voltage of 690 V and DC voltage of 500 V to handle diverse electrical systems.

Compact dimensions with 130 mm height, 120 mm width, and 82.5 mm depth suitable for industrial panels. Lever type reset actuator allows easy manual operation and reset after tripping. Conforms to CE, IEC, REACH, and RoHS standards for safety and environmental compliance.

Manufactured in Italy, ensuring high build quality and international standards. Explore our comprehensive range of circuit breakers at EnvMart for reliable electrical protection solutions from established brands like ABB.
