ABB Molded Case Circuit Breaker XT4H 4-Pole 40A 690V AC Breaking Capacity 100kA Fixed

ABB XT4H Molded Case Circuit Breaker 4-Pole 40A, model 1SDA068536R1 XT4H 160 Ekip I 40A FF is a high-performance electrical protection device designed for industrial, commercial, and manufacturing electrical installations. This fixed type MCCB (Molded Case Circuit Breaker) is rated for an operational voltage of 690V AC with an insulation rating of 1000V Ui, providing reliable circuit protection in demanding environments.

The breaker features a 4-pole configuration with front fixed terminals that allow secure connection and ease of installation. Its 40A current rating and 100kA breaking capacity ensure it can safely interrupt high fault currents, protecting equipment and personnel from electrical hazards.

Constructed with a solid-state tripping mechanism, the XT4H series offers precise and rapid fault detection and interruption. The reset actuator is a lever type, facilitating convenient manual reset after a fault condition has been cleared.

Dimensions of the unit are 160mm in height, 140mm in width, and 82.5mm in depth, making it suitable for panel installations where space and compactness are important. The product conforms to CE, IEC, and RoHS standards confirming its compliance with international safety and environmental directives.

The ABB XT4H is classified as a Better World product designed for disassembly, emphasizing ABB's commitment to sustainability and efficient recycling. The short circuit performance level is rated as H, indicating high endurance and longevity under electrical stress.

This Molded Case Circuit Breaker is an ideal solution for use in electrical distribution panels in industrial, laboratory, HVAC, manufacturing, and commercial facilities requiring robust circuit isolation and protection capabilities. It is manufactured in Italy, reflecting quality engineering and reliability.

For further quality assurance and adherence to industry standards, this circuit breaker is CE, IEC, and RoHS certified. The ABB XT4H MCCB is a dependable choice for electrical professionals needing fixed type circuit breakers with solid-state releases and front terminals.

Designed for fixed mounting with front terminal connections providing secure electrical interfaces. Rated operational voltage of 690V AC with insulation voltage up to 1000V Ui for high voltage applications. Solid-state tripping mechanism delivers rapid and accurate fault interruption for system protection.

Compact form factor with precise dimensions suitable for panel mounting. Compliance with CE, IEC, and RoHS ensures safety, performance, and ecological standards. Reset actuator lever allows for easy manual reset post trip event.

Short circuit performance rated H for high fault current endurance. Manufactured in Italy adhering to stringent quality control. Explore more ABB circuit breakers on EnvMart for reliable and safe electrical solutions.
