ABB Molded Case Circuit Breaker 3-Pole 100A Breaking Capacity 100 kA Fixed Mount XT4H
Specifications
| Country of Origin | Italy |
|---|---|
| Range | XT4H |
| Brand | ABB |
| Height | 160mm |
| Model | XT4H |
| Depth | 82.5mm |
| Width | 105mm |
| Mount Type | Fixed |
| Current Rating | 100A |
| Series | 1SDA06 |
| Terminal type | Fixed |
| Breaking Capacity | 100kA |
| Number of Poles | 3 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Solid State |
| Reset Actuator Type | Lever |
| Short circuit performance level | H |
Key Features
- The circuit breaker has a current rating of 100A for reliable circuit protection.
- It features a breaking capacity of 100 kA ensuring safety under short circuit conditions.
- Designed with 3 poles and fixed terminals for secure installation.
- Rated operational voltage is 690 V AC with 1000 V insulation voltage.
- Includes a solid state tripping mechanism and lever reset actuator.
- Compact dimensions of 160 mm height, 105 mm width, and 82.5 mm depth support versatile mounting.
- The breaker conforms to CE, IEC, and RoHS standards for quality and environmental compliance.
- Manufactured in Italy with a high short circuit performance level H classification.
Product Description
ABB XT4H Molded Case Circuit Breaker model 1SDA068518R1 XT4H 160 Ekip I 100A FF is a robust 3-pole electrical protection device designed for industrial and commercial applications requiring reliable power interruption and circuit safety.
With a rated current of 100A and a breaking capacity of 100 kA, this fixed mounting breaker is engineered to handle high fault currents and protect electrical installations from damage.
It operates at a rated AC voltage of 690V and features 1000V insulation voltage, ensuring safe functionality within a wide range of electrical systems. The front terminal design facilitates easy wiring and maintenance.
The solid state tripping mechanism provides precise protection with a lever for manual reset. These characteristics make it suitable for use in electrical panels, distribution boards, and control systems in industrial, manufacturing, commercial, and utility sectors.
Measuring 160 mm in height, 105 mm in width, and 82.5 mm in depth, the device offers a compact footprint that supports dense electrical installations. It is manufactured to meet CE, IEC, and RoHS standards, assuring compliance with international safety and environmental regulations.
The breaker supports short circuit performance level H, enhancing safety during fault conditions. Its construction and design focus on durability, safety, and ease of use in demanding electrical environments. Manufactured in Italy, the product reflects high quality and reliability benchmarks.
This ABB molded case circuit breaker is part of the XT4H range and Series 1SDA06, tailored for applications requiring consistent performance and robust circuit protection.
Explore more high-quality circuit breakers and electrical components available in the Molded Case Circuit Breaker category at EnvMart to meet your industrial and commercial power protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ABB Molded Case Circuit Breaker has a current rating of 100A, providing reliable circuit protection.
It features a breaking capacity of 100 kA, ensuring safety under short circuit conditions.
This unit is designed with 3 poles, allowing for effective circuit protection in three-phase systems.
The rated operational voltage is 690 V AC, with an insulation voltage of 1000 V.
It includes a solid state tripping mechanism, which provides precise protection against overloads and short circuits.
The compact dimensions are 160 mm in height, 105 mm in width, and 82.5 mm in depth, supporting versatile mounting options.
It conforms to CE, IEC, and RoHS standards, ensuring compliance with international safety and environmental regulations.
This model features a lever reset actuator for manual resetting after a trip event.
It is manufactured in Italy, reflecting high quality and reliability benchmarks.
The breaker supports a short circuit performance level of H, enhancing safety during fault conditions.
This model is designed for fixed mounting, ensuring secure installation in electrical panels and distribution boards.
It is suitable for use in electrical panels, distribution boards, and control systems in industrial, manufacturing, commercial, and utility sectors.
