ABB Tmax XT Molded Case Circuit Breaker 4-Pole 80A Breaking Capacity 85 kA Fixed 1SDA068223R1 XT3S 250 TMD 80A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 150mm |
| Model | 1SDA068223R1 XT3S 250 TMD 80A FF |
| Depth | 70mm |
| Width | 140mm |
| Mount Type | Fixed |
| Current Rating | 80A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 85kA |
| Number of Poles | 4 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 80 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Designed for fixed mounting with front terminals for secure connections.
- Rated for 690V AC and 500V DC operations.
- Utilizes thermal magnetic tripping mechanism for reliable protection.
- Compact dimensions with 150mm height, 140mm width, and 70mm depth.
- Complies with CE, IEC, and RoHS standards for safety and quality.
- Incorporates lever type reset actuator for easy manual operation.
- Rated impulse withstand voltage of 8 kV ensures robust performance.
- Suitable for industrial and commercial electrical protection applications.
Product Description
ABB 1SDA068223R1 XT3S 250 TMD 80A FF Molded Case Circuit Breaker is a 4-pole device designed for fixed mounting in electrical control and distribution systems. It supports a rated current of 80 amperes and provides a breaking capacity of 85 kiloamperes, ensuring effective protection against overcurrent and short circuit events. Designed for both alternating current (690 V AC) and direct current (500 V DC), this breaker is versatile for various industrial electrical applications.
The breaker features a thermal magnetic tripping mechanism, offering both thermal overload and magnetic short-circuit protection. The lever-type reset actuator allows convenient manual resetting after a trip. With compact dimensions of 150 mm height, 140 mm width, and 70 mm depth, it is suitable for installation in standard electrical panels.
Certified to meet CE, IEC, and RoHS standards, this product guarantees compliance with international safety and environmental directives. The rated impulse withstand voltage of 8 kV provides resilience against voltage spikes.
This molded case circuit breaker is ideal for industrial, manufacturing, HVAC, and commercial electrical systems requiring reliable circuit protection with high breaking capacities.
Designed for fixed mounting with front terminals ensuring secure connection. Thermal magnetic tripping provides dependable protection. Compact size enables ease of integration within electrical panels. Compliance with CE, IEC, and RoHS standards confirms quality and safety.
Rated for both AC and DC voltages spanning 690V AC and 500V DC. Lever reset actuator facilitates straightforward manual operation. High breaking capacity of 85 kA supports demanding industrial environments. Rated impulse withstand voltage of 8 kV safeguards against voltage surges.
Explore EnvMart’s category for Molded Case Circuit Breakers to find complementary and compatible industrial electrical protection devices.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 85 kiloamperes (kA).
The rated current for this model is 80 amperes (A).
This circuit breaker has a height of 150 mm, a width of 140 mm, and a depth of 70 mm.
It is rated for 690V AC and 500V DC operations.
The thermal magnetic tripping mechanism provides protection against both thermal overload and magnetic short-circuit events.
This model features a lever-type reset actuator for convenient manual resetting after a trip.
It complies with CE, IEC, and RoHS standards, ensuring safety and quality.
The rated impulse withstand voltage is 8 kV, providing resilience against voltage spikes.
Yes, it is designed for fixed mounting with front terminals for secure connections.
This circuit breaker belongs to the Tmax XT series.
It is suitable for industrial, manufacturing, HVAC, and commercial electrical protection applications.
The country of origin for this product is Italy.
