ABB Tmax XT Molded Case Circuit Breaker 3-Pole 25A Breaking Capacity 85 kA Fixed 1SDA068301R1 XT4S 160 TMD 25A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 25A Breaking Capacity 85 kA Fixed 1SDA068301R1 XT4S 160 TMD 25A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068301R1 XT4S 160 TMD 25A FF
Depth	82.5mm
Width	105mm
Mount Type	Fixed
Current Rating	25A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	25 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Rated current of 25 A for precise circuit protection.
Supports AC voltage up to 690 V and DC voltage up to 500 V.
Includes front fixed terminals for secure connections.
Compact design with 160mm height, 105mm width, and 82.5mm depth.
Complies with CE, IEC, and RoHS standards for quality assurance.
Equipped with a lever reset actuator for ease of operation.
Designed for industrial and commercial electrical systems requiring reliable circuit interruption.
Made in Italy with sustainability considerations including design for disassembly.

Product Description

The ABB 1SDA068301R1 XT4S 160 TMD 25A FF Tmax XT Molded Case Circuit Breaker is a high-performance 3-pole fixed circuit breaker designed to provide robust protection for electrical installations.

With a rated current of 25 amperes, this device can effectively handle a rated AC voltage of 690 V and DC voltage of 500 V, suitable for a wide range of industrial and commercial electrical applications.

The circuit breaker features a breaking capacity of 85 kA, ensuring safety against short circuits and overloads with its thermal magnetic trip mechanism providing precise trip performance and quick response to fault conditions.

Its compact dimensions - 160mm height, 105mm width, and 82.5mm depth - allow for efficient installation within control panels and switchboards. The front fixed terminals assure secure wiring and maintenance convenience, while the lever reset actuator facilitates easy reset after trip events.

Manufactured under strict CE, IEC, and RoHS standards, the ABB Tmax XT series emphasizes quality, reliability, and environmental responsibility with a design focused on sustainability and disassembly.

This circuit breaker is ideal for integration in electrical automation, control systems, industrial machinery protection, and electrical distribution units. Rated current of 25 A for precise circuit protection. Supports AC voltage up to 690 V and DC voltage up to 500 V.

Includes front fixed terminals for secure connections. Compact design with 160mm height, 105mm width, and 82.5mm depth. Complies with CE, IEC, and RoHS standards for quality assurance. Equipped with a lever reset actuator for ease of operation.

Designed for industrial and commercial electrical systems requiring reliable circuit interruption. Made in Italy with sustainability considerations including design for disassembly. Browse the Electronics & Electricals category on EnvMart for more high-quality circuit breakers and accessories from ABB and other top brands.
