ABB Molded Case Circuit Breaker 4-Pole 250A Current Rating Breaking Capacity 150kA Fixed Mount Type 690V AC 500V DC XT4L



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4L
Brand	ABB
Height	160mm
Model	XT4L
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	250A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

This circuit breaker supports AC voltage up to 690V and DC voltage up to 500V.
Equipped with a lever reset actuator for quick manual operation.
It features a fixed terminal type with four poles for broad application.
Compact dimensions measure 160mm height, 140mm width, and 82.5mm depth.
Designed for high electrical durability with 120 cycles per hour and 1000 V rated insulation voltage.
Meets international standards including CE, IEC, and RoHS compliance.
Constructed for industrial, commercial, and automation use, ensuring reliable protection against faults.
Manufactured in Italy with a focus on sustainability and designed for disassembly.

Product Description

ABB XT4L Molded Case Circuit Breaker 4-Pole 250A, model 1SDA06 XT4L, is designed for dependable electrical system protection in industrial, laboratory, commercial, and automation environments. It features a fixed mount type and a high breaking capacity of 150 kA to safely interrupt fault currents. The unit supports rated AC voltage of 690V and DC voltage of 500V, ensuring robust performance across different circuit types.

The breaker includes a lever reset actuator for quick and secure manual resetting after trips. Its fixed terminal type with four poles provides widespread application flexibility and durability. The compact form factor with dimensions of 160mm height, 140mm width, and 82.5mm depth allows for space-efficient installation.

Engineered to international CE, IEC, and RoHS standards, the ABB XT4L circuit breaker ensures compliance and reliability. It delivers electrical durability rated at 120 cycles per hour and an insulation voltage of 1000V, capable of maintaining operational integrity under demanding conditions.

The product complies with Better World objectives, being designed for disassembly to promote sustainable manufacturing and recycling. This breaker suits applications in electrical distribution, manufacturing plants, HVAC systems, and water treatment plants, offering excellent protection against overloads, short circuits, and electrical faults.

This circuit breaker supports AC voltage up to 690V and DC voltage up to 500V. Equipped with a lever reset actuator for quick manual operation. It features a fixed terminal type with four poles for broad application. Compact dimensions measure 160mm height, 140mm width, and 82.5mm depth.

Designed for high electrical durability with 120 cycles per hour and 1000 V rated insulation voltage. Meets international standards including CE, IEC, and RoHS compliance. Manufactured in Italy focusing on sustainable design and disassembly.

Provides a short circuit performance level rated as L for enhanced protection.
