ABB Tmax XT Molded Case Circuit Breaker 3-Pole 25A Breaking Capacity 200 kA Fixed 1SDA067982R1 XT2V 160 Ekip LSI 25A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 25A Breaking Capacity 200 kA Fixed 1SDA067982R1 XT2V 160 Ekip LSI 25A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067982R1 XT2V 160 Ekip LSI 25A FF
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	25A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	200kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	25 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed for rated AC voltage of 690 V at 50/60 Hz frequency.
Features solid state tripping mechanism with Ekip LSI release for precise protection.
Compact dimensions of 130 mm height, 90 mm width, and 82.5 mm depth.
Compliant with CE, IEC, and RoHS standards ensuring reliable safety and quality.
Equipped with lever reset actuator and fixed mounting type for secure installation.
Rated impulse withstand voltage up to 8 kV for enhanced durability.
Manufactured in Italy with sustainability claims including designed for disassembly.
Suitable for industrial and commercial electrical distribution and protection applications.

Product Description

ABB 1SDA067982R1 XT2V 160 Ekip LSI 25A FF Molded Case Circuit Breaker belongs to the Tmax XT range known for high performance and durability. This 3-pole fixed terminal circuit breaker has a current rating of 25 A and a breaking capacity of 200 kA, suitable for demanding electrical distribution requirements.

Operating at a rated AC voltage of 690 V with a frequency of 50/60 Hz, the device features a solid state tripping mechanism equipped with Ekip LSI technology, providing precise and reliable overload and short-circuit protection.

The compact size, with dimensions of 130 mm height, 90 mm width, and 82.5 mm depth, allows easy integration into standard electrical panels. The reset actuator lever and fixed mounting type enhance usability and secure connection.

Certified to CE, IEC, and RoHS standards, this circuit breaker meets international safety and environmental compliance requirements. The rated impulse withstand voltage is 8 kV, ensuring robustness under transient voltage conditions.

Manufactured in Italy, the product is part of ABB’s Better World program, designed for disassembly to promote sustainability. It is ideally suited for industrial, commercial, and HVAC applications needing reliable circuit protection.

Rated for 25 A current to protect electrical circuits against overloads and faults. Breaking capacity of 200 kA allows safe interruption of high short-circuit currents. Solid state Ekip LSI tripping mechanism offers adjustable and advanced protective functions.

Fixed installation with front terminals provides reliable electrical connections. Compact dimensions facilitate space-efficient panel designs. Compliance with international standards ensures operational safety and environmental responsibility.

Designed for industrial and commercial power distribution boards. Manufactured with high quality materials and precise engineering in Italy.

Explore the ABB catalog on EnvMart for more high-quality Molded Case Circuit Breakers and electrical protection solutions designed to meet diverse industrial and commercial power control requirements.
