SICK Background Suppression Photoelectric Sensor Block Sensor, Detection Range 60 mm to 900 mm, PNP Output IRT-P232C83
Specifications
| Country of Origin | United States |
|---|---|
| Brand | SICK |
| Response time | 2ms |
| Light Source | Infrared LED |
| Detection range | 60 mm → 900 mm |
| Model | IRT-P232C83 |
| IP Rating | IP67 |
| Housing Material | Plastic |
| Output type | PNP |
| Series | ZoneControl |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -40°C |
| Maximum Current | 100mA |
| Terminal type | 4-Pin Connector |
| Interface Type | 4-Pin, M12 Connector |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | CE Certified, UL Certified |
| Sensor Style | Block |
| Three mounting types | mounting between the rollers (R/IR), mounting on the side frame (ZLM), or mounting above the belt (WLR) |
| Three types of logic | single feed, single feed with sleep function, block (slug) feed |
Key Features
- Detection range spans from 60 mm to 900 mm with precise background suppression.
- Equipped with a PNP output and 4-pin M12 connector interface for easy integration.
- Built with a durable plastic housing rated IP67 for dust and water resistance.
- Operates reliably between temperatures of -40°C to 60°C with 2 ms response time.
- Infrared LED light source ensures consistent sensing performance.
- Certified to CE and UL standards for industrial safety compliance.
- Supports ZoneControl series with three mounting types for versatile conveyor applications.
- Designed for zero pressure accumulation and automated load transfer in manufacturing lines.
Product Description
The SICK IRT-P232C83 background suppression Photoelectric Sensor provides highly reliable detection with block sensor technology for industrial automation needs. This sensor features a broad detection range from 60 mm to 900 mm, enabling precise sensing in conveyor belt systems and other manufacturing lines. Its robust plastic housing with an IP67 rating offers excellent protection against dust and water, making it suitable for harsh industrial environments.
Designed with a PNP output and a 4-pin M12 connector, the sensor is easy to install and integrate with existing automation control gear. The infrared LED light source delivers consistent detection performance, with a quick response time of only 2 ms. Operating temperature ranges from -40°C to 60°C ensure dependable functionality in diverse conditions.
The sensor is CE and UL certified, fulfilling critical safety standards necessary for industrial applications. As part of the ZoneControl series, IRT-P232C83 supports three mounting types including between rollers, side frame, or above the belt, facilitating flexible installation options tailored to specific conveyor system requirements.
Its application scope includes automatic wheel and tire separation, zero pressure accumulation, and controlled load transfer on conveyor belts without need for additional PLCs or complex programming. The modular design allows quick system expansion or modification while maintaining high throughput efficiency.
This sensor is manufactured in the United States and offers a robust solution for advanced automation and control scenarios in commercial, manufacturing, and material handling industries.
Detection range from 60 mm to 900 mm ensures versatile sensing capability. PNP output and 4-pin M12 connector enable easy connectivity. IP67 rated plastic housing withstands harsh industrial conditions. Operates between -40°C and 60°C with a 2 ms response time.
Infrared LED light source provides stable detection performance. CE and UL certifications confirm safety compliance. Supports various mounting options for conveyor integration. Facilitates zero pressure accumulation and automated load transfer.
Explore more products in the Sensors category at EnvMart for advanced industrial automation and control solutions.
