Schneider Electric ComPact NSXm Molded Case Circuit Breaker 4-Pole 80A 36kA Breaking Capacity 690V AC DIN Rail LV426326
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426326 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 80A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 36kA |
| Number of Poles | 4 |
| Standards/Approvals | IEC, CCC, CE, EAC, EN, RoHS |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- Compact NSXm series design suited for industrial and commercial electrical protection.
- Four poles provide comprehensive circuit control and protection.
- Current rating of 80 amperes supports medium-load electrical systems.
- Thermal magnetic tripping mechanism detects overload and short circuits.
- Toggle switch actuator allows easy reset and manual control.
- Screw terminal type ensures solid electrical connection and durability.
- Designed for DIN Rail mounting with standard 4.5 mm mount hole size.
- Complies with IEC, CCC, CE, EAC, EN, and RoHS standards for safety and environmental compliance.
Product Description
Schneider Electric LV426326 is a high-performance molded case circuit breaker (MCCB) from the ComPact NSXm range, designed to deliver robust protection for electrical circuits in industrial, commercial, and residential applications. Featuring a 4-pole configuration with an 80 ampere current rating, this breaker effectively manages medium-load electrical systems with superior reliability.
The unit incorporates a thermal magnetic tripping mechanism, combining thermal protection against prolonged overloads and magnetic protection for rapid response to short circuits. This type D tripping characteristic makes it suitable for motor protection and other inductive loads.
Its compact form factor allows for DIN Rail mounting, facilitating straightforward integration into electrical panels and distribution boards. The breaker is equipped with screw-type terminals that ensure firm and lasting connections, while the toggle switch actuator provides intuitive manual control and resetting capability.
Meeting multiple international standards including IEC, CCC, CE, EAC, EN, and RoHS, this circuit breaker ensures compliance with stringent safety and environmental guidelines. The breaker measures 137 mm in height and depth, and 80 mm in width, providing a balance of compactness and functionality.
Compact NSXm design enables flexible use across various electrical systems. 4 poles provide enhanced circuit protection and phase control. 80A current rating suits medium power applications. Thermal magnetic trip mechanism offers dependable overload and short circuit protection.
Toggle switch actuator simplifies breaker operation and resetting. Screw terminals ensure strong electrical connections. DIN Rail mount compatibility streamlines panel installations. International approvals affirm product safety and quality compliance.
Dimensioned for efficient space utilization in electrical cabinets.
This Molded Case Circuit Breaker is ideal for industrial automation, manufacturing, electrical distribution, and HVAC systems requiring reliable, standards-compliant circuit protection. Its robust construction and versatile features make it suitable for diverse electrical infrastructure setups.
Explore Schneider Electric products and accessories on EnvMart for comprehensive solutions in electrical protection and automation.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This molded case circuit breaker has a current rating of 80 amperes, suitable for medium-load electrical systems.
The breaking capacity of this circuit breaker is 36kA, providing robust protection against short circuits.
It features a 4-pole configuration, allowing for comprehensive circuit control and protection.
This unit utilizes a thermal magnetic tripping mechanism, which offers protection against overloads and short circuits.
The rated AC voltage for this model is 690V, making it suitable for various electrical applications.
The breaker measures 137 mm in height and depth, and 80 mm in width, allowing for efficient space utilization in electrical panels.
It is designed for DIN Rail mounting, facilitating straightforward integration into electrical panels.
The circuit breaker is equipped with screw-type terminals, ensuring solid electrical connections.
This model complies with multiple international standards including IEC, CCC, CE, EAC, EN, and RoHS for safety and environmental compliance.
It features a toggle switch actuator, allowing for easy manual control and resetting of the breaker.
This breaker is suitable for industrial automation, manufacturing, electrical distribution, and HVAC systems requiring reliable circuit protection.
The tripping characteristic of this model is Type D, making it suitable for motor protection and inductive loads.
