Schneider Electric ComPact Compact NSXm Molded Case Circuit Breaker 4-Pole 16A 690V AC 70kA Thermal Magnetic LV426570
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426570 |
| Depth | 80mm |
| Width | 137mm |
| Mount Type | Clip-on |
| Current Rating | 16A |
| Series | Compact NSXm |
| Terminal type | Screw |
| Breaking Capacity | 70kA |
| Number of Poles | 4 |
| Standards/Approvals | CCC, CE, EAC, EN, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Designed for high performance in electrical distribution systems with a current rating of 16A.
- Four-pole configuration provides comprehensive circuit protection.
- Breaking capacity of 70 kA ensures high fault current interruption capabilities.
- Clip-on mount type for easy installation and maintenance.
- Reset actuator type is a toggle switch for quick manual operation.
- Thermal magnetic tripping mechanism provides reliable protection against overload and short circuit.
- Compliant with international standards including CCC, CE, EAC, EN, IEC, and RoHS.
- Compact NSXm series designed for compact modularity and robust operation.
Product Description
Schneider Electric LV426570 Molded Case Circuit Breaker (MCCB) is a 4-pole device designed for robust electrical circuit protection in industrial, commercial, and infrastructure applications. Rated for 16A current and 690V AC voltage, this model features a high breaking capacity of 70 kA, capable of interrupting large fault currents safely.
The breaker uses a thermal magnetic tripping mechanism with Type D tripping characteristics to protect circuits from overloads and short circuits effectively. Its clip-on mount design facilitates straightforward panel installation and maintenance, while the toggle switch reset actuator allows for quick user operation.
With screw terminal connections, the LV426570 ensures secure and reliable wiring integrity. The Compact NSXm series by Schneider Electric offers compact dimensions (137mm width, 137mm height, and 80mm depth), optimizing space without compromising performance.
This MCCB complies with several international safety and quality standards, including CCC, CE, EAC, EN, IEC, and RoHS, ensuring adherence to global electrical protection norms. Designed for efficient and reliable circuit protection in electrical distribution systems.
Offers high breaking capacity suitable for demanding industrial environments. Compact form factor ideal for space-restricted panel installations. Thermal magnetic tripping mechanism for dependable overload and short circuit response.
Comprehensive compliance with global standards ensures quality and safety. Easy installation via clip-on mount type and screw terminals. Toggle switch actuator for fast reset post-trip. MCCB suitable for industrial, manufacturing, commercial, and infrastructure electrical applications.
Explore the full range of high-quality circuit protection solutions from Schneider Electric at EnvMart. Offering trusted brand reliability and certified industrial components for your electrical distribution needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this circuit breaker is 16A.
It has a breaking capacity of 70 kA, allowing it to interrupt large fault currents safely.
The rated AC voltage for the LV426570 is 690V.
This circuit breaker is a 4-pole device, providing comprehensive circuit protection.
It uses a thermal magnetic tripping mechanism with Type D tripping characteristics for effective protection against overloads and short circuits.
The LV426570 features a clip-on mount type, which facilitates easy installation and maintenance.
The dimensions are 137mm in width, 137mm in height, and 80mm in depth.
It has a toggle switch reset actuator for quick manual operation after a trip.
It complies with several international standards, including CCC, CE, EAC, EN, IEC, and RoHS.
The LV426570 uses screw terminal connections, ensuring secure and reliable wiring integrity.
This molded case circuit breaker is designed for industrial, commercial, and infrastructure electrical applications.
It belongs to the Compact NSXm series, which is designed for compact modularity and robust operation.
