Banner Through Beam Photoelectric Sensor, Block Sensor, 2 m Detection Range, Bipolar Output, IP67 Rated Q12RB6RQ
Specifications
| Country of Origin | United States |
|---|---|
| Brand | Banner |
| Response time | 700μs |
| Light Source | LED |
| Detection range | 2 m |
| Model | Q12RB6RQ |
| IP Rating | IP67 |
| Mount Type | Threaded |
| Housing Material | Thermoplastic |
| Output type | Bipolar |
| Series | Q12 |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | -20°C |
| Maximum Current | 20mA |
| DetectIon Type | Through Beam |
| Terminal type | Connector |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | CE Certified, cULus Listed |
| Sensor Style | Block |
| Solid-state, bipolar outputs | one current sourcing (PNP) and one current sinking (NPN) standard on 4-wire models |
Key Features
- Miniature self-contained sensor with bright 640 nm visible red LED light source.
- Bipolar solid-state outputs with both PNP and NPN current options on 4-wire models.
- Threaded mounting for versatile installation in industrial and automation environments.
- Operates in temperatures ranging from -20°C to 55°C with robust IP67 protection.
- CE certified and cULus listed for international safety and quality standards compliance.
- Compact 8 mm housing ideal for tight installation spaces.
- Models available with chemical-resistant PFA jacket for harsh washdown conditions.
- Response time of 700 microseconds ensures fast detection and control.
Product Description
Banner Q12RB6RQ is a high-performance Through Beam Photoelectric Sensor designed for precise object detection up to 2 meters. This block style sensor features a robust thermoplastic housing with an IP67 rating, making it suitable for harsh industrial and automation environments where reliability and durability are critical. Its bipolar outputs provide both sourcing (PNP) and sinking (NPN) solid-state signals, enabling flexible integration with a wide range of control systems.
The sensor utilizes a bright visible red LED light source of 640 nm wavelength, providing clear detection feedback. Its compact 8 mm threaded housing allows for easy installation in confined spaces. Operating temperature range from -20°C to 55°C ensures stable functionality under varying environmental conditions. The sensor meets CE and cULus certifications, underscoring its compliance with essential quality and safety standards.
This model is part of Banner's Q12 series, known for miniature self-contained sensors optimized for automation, manufacturing, and process control applications. Optional versions include models with PFA chemical-resistant jackets, rated for 1200 psi washdown scenarios, suitable for harsh and demanding industrial washdown environments.
With a rapid response time of 700 microseconds, this sensor delivers timely detection signals for high-speed automation tasks. Its solid-state bipolar outputs simplify wiring by providing both PNP and NPN signals on 4-wire models. The sensor is powered by a maximum DC voltage of 30V and supports a maximum current of 20mA, balancing performance with energy efficiency.
This Banner Photoelectric Sensor is an ideal solution for electrical, automation, and control gear systems requiring reliable and compact object detection. Typical applications include factory automation lines, packaging machinery, agricultural equipment, and HVAC system monitoring.
Miniature 8 mm thermoplastic housing with IP67 protection. Bright 640 nm red LED light source for clear beam detection. Bipolar solid-state outputs with PNP and NPN on 4-wire models. Threaded mounting supports flexible installation options.
Operating temperature from -20°C to +55°C for diverse environments. CE and cULus listed standards ensure safety and compliance. Chemical-resistant PFA jacket available for harsh washdown use. 700μs response time suits fast industrial processes.
Explore more Banner Sensors and Photoelectric Sensors on EnvMart for advanced automation and control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The detection range of this sensor is up to 2 meters.
It features bipolar solid-state outputs, including one current sourcing (PNP) and one current sinking (NPN) on 4-wire models.
This sensor operates within a temperature range of -20°C to 55°C.
The response time is 700 microseconds, allowing for fast detection and control.
It has an IP67 rating, making it suitable for harsh environments.
It uses a bright 640 nm visible red LED light source for clear detection feedback.
The housing is made of thermoplastic, designed for durability in industrial settings.
It features a threaded mounting design, allowing for versatile installation options.
The maximum DC voltage is 30V and the maximum current is 20mA.
Yes, it is CE certified and cULus listed, ensuring compliance with international safety and quality standards.
It is suitable for applications in factory automation, packaging machinery, agricultural equipment, and HVAC system monitoring.
Yes, optional versions include models with a chemical-resistant PFA jacket for harsh washdown conditions.
