Igus Chainflex CF130.UL Control Cable, 4 Cores, 2.5mm² 13 AWG, Unscreened, 50 m, Grey Thermoplastic CF130.25.04.UL (50m)

Free Delivery in India | Lowest Global Shipping Charges

Igus Chainflex CF130.UL Control Cable, 4 Cores, 2.5mm² 13 AWG, Unscreened, 50 m, Grey Thermoplastic CF130.25.04.UL (50m)

Name: Igus Chainflex CF130.UL Control Cable, 4 Cores, 2.5mm² 13 AWG, Unscreened, 50 m, Grey Thermoplastic CF130.25.04.UL (50m)
Brand: IGUS
SKU: 391541
Price: 13.44 USD
Availability: InStock



Category Control Cable Brand IGUS Condition New

Specifications

Country of Origin	Germany
Voltage	300, 500V
Brand	Igus
Model	CF130.25.04.UL (50m)
Cable Length	50m
Series	Chainflex CF130.UL
Outside diameter	9.5mm
Maximum Operating Temperature	70°C
Number Of Cores	4
Conductor Material	Copper
Minimum Operating Temperature	-15°C
Jacket Material	Thermoplastic Elastomer
Standards/Approvals	EN, CE
Jacket Colour	Grey
Fire Behaviour	Flame Retardant
American Wire Gauge	13AWG
Screened/Unscreened	Unscreened
Conductor Type	Stranded
Cable CSA	2.5mm²

Key Features

The cable is rated for 300 and 500 volts suitable for control cable applications.
It is made with stranded copper conductors for reliable signal transmission.
The thermoplastic elastomer jacket provides excellent abrasion resistance and chemical protection.
The cable length is a continuous 50 meters, ideal for flexible and fixed installations.
It operates reliably in temperatures ranging from -15°C to 70°C.
The unscreened design supports indoor or above-freezing outdoor use without oil exposure.
The outside diameter of the cable is 9.5 mm for space-saving installations.
The cable is flame retardant, complying with multiple fire safety standards.

Product Description

Igus CF130.25.04.UL (50m) Control Cable is a high-quality, unscreened 4-core cable designed for medium duty industrial and automation applications. Featuring 2.5mm² (13 AWG) stranded copper conductors, this cable ensures durable electrical performance and flexibility. The grey thermoplastic elastomer sheath offers excellent abrasion resistance, making it suitable for harsh chemical and oil environments often encountered in manufacturing and packaging industries.

Rated for 300/500 volts and flame retardant according to IEC 60332-1-2, CEI 20-35, FT1, and VW1 standards, the cable is flame resistant and meets EN and CE certifications, ensuring operational safety in demanding environments. The armoured construction provides enhanced mechanical protection, especially valuable in industrial settings where cables are subject to movement and mechanical impact.

The CF130.UL series is optimized for use in e-chain cable carriers and flexible applications, supporting installation in wood and stone processing, handling, and adjusting equipment. The cable's small outside diameter of 9.5 mm and patented bundled core design allow for tight bend radii, facilitating space-saving layouts.

The cable operates reliably between -15°C and 70°C, making it suitable for indoor applications and outdoor use only above freezing temperatures. It is silicone-free and RoHS lead-free compliant, promoting environmental safety.

The cable length is 50 meters, supplied as a continuous spool to minimize joints. Constructed with stranded copper conductors for enhanced flexibility and conductivity. The thermoplastic elastomer jacket provides superior abrasion and chemical resistance.

Armoured cable suitable for industrial environments with enhanced mechanical protection. Flame retardant rated with multiple international fire safety certifications. Metal braid screen is absent as this is an unscreened cable design for specific applications.

Complies with EN, CE standards, and RoHS directive for lead-free safety. Ideal for control cabling in automation, manufacturing, and packaging industries. Designed for medium duty applications in e-chain systems with guaranteed service life.

Manufactured in Germany ensuring premium build quality and reliability. Explore the wide range of control and industrial cables available for various electrical and automation needs at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The cable is rated for 300 and 500 volts, making it suitable for various control cable applications.

It operates reliably at temperatures ranging from -15°C to 70°C.

This control cable features 4 cores, providing multiple pathways for signal transmission.

The outside diameter of the cable is 9.5 mm, allowing for space-saving installations.

It is constructed with stranded copper conductors and a thermoplastic elastomer jacket, offering excellent abrasion resistance and chemical protection.

The cable is suitable for outdoor use only above freezing temperatures, as it is unscreened and not designed for exposure to oil.

It is flame retardant and complies with multiple fire safety standards, including IEC 60332-1-2, CEI 20-35, FT1, and VW1.

The cable length is a continuous 50 meters, which minimizes the number of joints required in installations.

The cable has an American Wire Gauge (AWG) rating of 13 AWG, which corresponds to a cross-sectional area of 2.5 mm².

This model is optimized for medium duty industrial and automation applications, particularly in e-chain systems.

It is manufactured in Germany, ensuring a high standard of build quality and reliability.

Yes, the cable is silicone-free and RoHS lead-free compliant, promoting environmental safety.
