SMC Basic Pneumatic Manual Control Valve VM100 Series NPT Rc R 1/8 3-Port 2-Position Pneumatic Relay Valve

Free Delivery in India | Lowest Global Shipping Charges

SMC Basic Pneumatic Manual Control Valve VM100 Series NPT Rc R 1/8 3-Port 2-Position Pneumatic Relay Valve



Category Pneumatic Manual Control Valve Brand SMC Condition New

Specifications

Country of Origin	Japan
Brand	SMC
Body Material	Zinc Die Cast Alloy
Maximum Operating Pressure	1 Mpa
Model	VM100
Series	VM100
Number Of Ports	3
Maximum Operating Temperature	+60°C
Thread Size	1/8
Number of Positions	2
Port Size	R 1/8
Minimum Operating Temperature	-5°C
Maximum Flow Rate	1088L/min
Control Mechanism	Basic
Connection Thread Standard	NPT, Rc
Valve Function	Pneumatic Relay
Control Button/Switch Colour	Yellow, Black, Green, Red
SMC Basic 3/2 Pneumatic Manual Control Valve VM100 Series, Rc 1/8, 1/8inBrand	SMC

Key Features

Basic control mechanism with roller lever and plunger actuator options.
Port size R 1/8 compatible with NPT and Rc thread standards.
Maximum operating pressure of 1 MPa and flow rate up to 1088 L/min.
Suitable for operating temperature range of -5°C to +60°C.
Control button/switch colours available in yellow, black, green, and red.
Compact, lightweight design ideal for pneumatic control panels and workpiece position confirmation.
3 ports and 2 positions provide reliable pneumatic relay control.
Manufactured in Japan ensuring high quality and reliability.

Product Description

SMC VM130-01-00A is a basic pneumatic manual control valve from the VM100 Series with a zinc die cast alloy body, designed for industrial pneumatic applications requiring reliable control.

This valve features a 3-port, 2-position pneumatic relay function and supports R 1/8 port size with NPT and Rc threading for versatile connection options. The control mechanism is basic and includes roller lever and plunger actuator variants, allowing easy actuation under harsh environments.

The maximum operating pressure is 1 MPa with a maximum flow rate capability of 1088 L/min, suitable for diverse industrial uses such as pneumatic control panels, air signal switching, and position confirmation of workpieces using pneumatic signals.

The valve operates efficiently within a temperature range of -5°C to +60°C, ensuring durability and performance in varying environments. Control buttons and switches come in multiple colours: yellow, black, green, and red, supporting application-specific colour coding.

Manufactured in Japan, the VM130-01-00A offers reliability and high build quality. Its compact and lightweight design offers easier integration into pneumatic systems requiring precise manual control of air flow.

Basic pneumatic control mechanism with multiple actuator options for flexibility. 3 ports and 2 positions allowing reliable control of pneumatic circuits. Compatible with NPT and Rc threaded connections port size R 1/8. Flow rate up to 1088 L/min under 1 MPa operating pressure.

Operating temperature range from -5°C up to +60°C suitable for industrial settings. Various control button colours for easy identification and use in control panels. This Pneumatic Manual Control Valve is ideal for industrial, manufacturing, laboratory, and automation environments requiring robust, precise pneumatic relay control solutions.
