Banner Diffuse Photoelectric Sensor, Barrel Sensor, 450 mm Detection Range, NPN Output, IP67 Rated QS18VN6DQ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Banner |
| Response time | 600μs |
| Light Source | LED |
| Detection range | 450 mm |
| Model | QS18VN6DQ |
| IP Rating | IP67 |
| Mount Type | Screw |
| Housing Material | ABS |
| Output type | NPN |
| Series | QS18 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -20°C |
| Maximum Current | 25mA |
| DetectIon Type | Diffuse |
| Terminal type | Cable |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | IEC |
| Sensor Style | Barrel |
| Solid-state complementary (SPDT) | NPN or PNP (current sinking or sourcing), depending on model |
Key Features
- Compact QS18 barrel housing made from ABS material with included 3mm mounting hardware.
- Diffuse detection type using an LED light source providing stable object sensing.
- IP67 rated enclosure enables operation in harsh industrial environments.
- Operating voltage range from 10Vdc to 30Vdc with maximum current of 25mA.
- Fast response time of 600 microseconds suitable for high-speed automation tasks.
- Includes single turn sensitivity potentiometer for easy adjustment.
- Solid-state complementary SPDT output configurable as NPN current sinking.
- Operating temperature range from -20°C to +70°C for versatile deployment.
Product Description
Banner QS18VN6DQ Diffuse Photoelectric Sensor is designed for industrial automation and control applications requiring reliable detection of objects at a distance up to 450 mm. This sensor is housed in a compact ABS barrel style enclosure with a robust IP67 rating, ensuring protection against dust and water ingress suitable for demanding environments.
The sensor utilizes a diffuse detection mode with an LED light source to provide consistent sensing performance regardless of object color or shape variations. The NPN solid state complementary (SPDT) output offers current sinking capability, which is particularly compatible with typical automation control systems.
Operating with a supply voltage of 10 to 30 Vdc and a maximum current of 25 mA, the QS18VN6DQ provides efficient and low-power operation. Its rapid response time of 600 microseconds allows for fast detection cycles essential in high-speed production lines and manufacturing processes.
The sensor includes a single-turn sensitivity potentiometer, allowing for fine adjustment of detection sensitivity to optimize performance in diverse industrial scenarios. Mounting is facilitated via included 3 mm screws, and the sensor is supplied with a 2 meter cable for convenient wiring and installation.
With an operating temperature range from -20°C to +70°C and an IEC compliance standard, this photoelectric sensor barrell type is well-suited for use in industrial automation, manufacturing, material handling, and packaging lines requiring precise object detection under various conditions.
Compact QS18 barrel housing with ABS material and IP67 rating. Diffuse LED light source for stable optical sensing. NPN output type with solid-state complementary SPDT configuration. 10 to 30 Vdc supply, 25 mA maximum current for efficient operation.
Fast 600 microseconds response time for high-speed applications. Single turn sensitivity potentiometer for easy tuning. Screw mount type included with 3 mm hardware. Operates between -20°C and +70°C temperature range. 2 meter pre-cabled connection for convenient installation.
Ideal for automation, manufacturing, laboratory, packaging, and general industrial sensing tasks requiring precise diffuse photoelectric detection. Explore Banner and Photoelectric Sensor categories on EnvMart for more advanced sensing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The detection range of this model is up to 450 mm.
It features an NPN output type with a solid-state complementary SPDT configuration.
The operating voltage range is from 10 Vdc to 30 Vdc.
The maximum current rating for this model is 25 mA.
The response time is 600 microseconds, suitable for high-speed automation tasks.
The sensor is housed in a compact ABS barrel style enclosure.
This model has an IP67 rating, providing protection against dust and water ingress.
The operating temperature range is from -20°C to +70°C.
Mounting is facilitated via included 3 mm screws, making installation straightforward.
It uses an LED light source for stable object sensing.
The sensor complies with IEC standards.
Yes, it includes a single-turn sensitivity potentiometer for easy adjustment of detection sensitivity.
