STMicroelectronics 16 kB Parallel Interface Real Time Clock 24-Pin PCDIP 150 ns M48T12-150PC1

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics 16 kB Parallel Interface Real Time Clock 24-Pin PCDIP 150 ns M48T12-150PC1

Name: STMicroelectronics 16 kB Parallel Interface Real Time Clock 24-Pin PCDIP 150 ns M48T12-150PC1
Brand: STMicroelectronics
SKU: 379622
Price: 62.38 USD
Availability: InStock



Category Real Time Clock Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	8.89mm
Length	34.8mm
Model	M48T12-150PC1
Width	18.34mm
Mount Type	Through Hole
Maximum Operating Temperature	70°C
Package Type	PCDIP
Minimum Operating Temperature	0°C
Memory size	16kB
Interface Type	Parallel
Pin Count	24
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	4.5V
Supply Current	80mA
Organisation	2K x 8 bit
Number of Bits per Word	11
Maximum Random Access Time	150ns
Number of Words	2

Key Features

Real Time Clock combined with TIMEKEEPER® SRAM technology offers reliable data retention.
Parallel interface enables efficient communication and data transfer.
24-Pin PCDIP package suitable for through-hole mounting.
Operates between 0°C and 70°C, ideal for industrial environments.
Low supply current consumption of 80 mA ensures energy efficiency.
Supports 16 kB memory organized as 2K x 8 bits with 10-bit data bus width.
Maximum random access time of 150 ns for swift memory operations.
Embedded battery and quartz-based low power oscillator sustain clock/calendar functions.

Product Description

STMicroelectronics M48T12-150PC1 is a high-performance Real Time Clock device integrated with 16 kB TIMEKEEPER® SRAM memory. It combines a parallel interface with a built-in quartz oscillator and battery backup to maintain accurate real-time data and calendar functions, ensuring reliable timekeeping even during power interruptions.

The device utilizes a 24-pin PCDIP package designed for through-hole mounting, with compact physical dimensions of 34.8 mm length, 18.34 mm width, and 8.89 mm height. It supports a parallel data interface with a 10-bit bus width and memory organized as 2K x 8 bits, providing a total 16 kB storage capacity for non-volatile RAM applications.

Designed to operate within an ambient temperature range of 0°C to 70°C, the M48T12-150PC1 is suitable for industrial and embedded systems where reliable time tracking is critical. The device ensures fast data access with a maximum random access time of 150 nanoseconds, and an energy-efficient supply current of only 80 mA.

Offers robust real-time clock and calendar functionality with integrated battery backup. Employs TIMEKEEPER® technology for non-volatile SRAM memory retention. Compatible with 24-pin PCDIP through-hole mounting for ease of installation.

Wide supply voltage operating range ensures compatibility with various embedded systems. Compact size supports space-saving PCB designs. Low power consumption extends battery life and system efficiency. Ideal for applications in industrial automation, data logging, and time-sensitive embedded systems.

This Real Time Clock module from STMicroelectronics is ideal for use in industrial, laboratory, and embedded electronics applications that require reliable, accurate timekeeping combined with non-volatile memory storage. Available as a 24-pin through-hole component, it facilitates easy integration into various electronic systems.
