SICK Block Inductive Proximity Sensor NPN Flush Mount 30 V DC 200 mA 3 mm Detection IQ10-03BNSKW2S

Free Delivery in India | Lowest Global Shipping Charges

SICK Block Inductive Proximity Sensor NPN Flush Mount 30 V DC 200 mA 3 mm Detection IQ10-03BNSKW2S

Name: SICK Block Inductive Proximity Sensor NPN Flush Mount 30 V DC 200 mA 3 mm Detection IQ10-03BNSKW2S
Brand: SICK
SKU: 370244
Price: 118.77 USD
Availability: InStock



Category Inductive Proximity Sensor Brand SICK Condition New

Specifications

Country of Origin	Singapore
Brand	SICK
Length	28mm
Model	IQ10-03BNSKW2S
Depth	10.3mm
IP Rating	IP67, IP68
Width	16mm
Mount Type	Flush
Housing Material	Plastic
Output type	NPN
Series	IQ10
Maximum Operating Temperature	75°C
Minimum Operating Temperature	-25°C
Switching Current	200mA
Terminal type	Cable
Body Style	Block
Maximum dc Voltage	30V dc
Shielding	Unshielded
Maximum Switching Frequency	2kHz
Standards/Approvals	EN 60947-5-2
Maximum Supply Voltage	30V
Materials Detected	Metal
Maximum Detection	3mm

Key Features

The sensor features a block body style with dimensions 28 mm length, 16 mm width, and 10.3 mm depth.
It is designed for flush mounting and uses cable termination for electrical connection.
Operates at a maximum supply voltage of 30 V DC with a switching current rating of 200 mA.
Equipped with an NPN output type and capable of switching frequencies up to 2 kHz.
The device is unshielded and suitable for industrial environments with IP67 and IP68 ingress protection ratings.
Operates reliably within a temperature range of -25°C to 75°C.
Conforms to EN 60947-5-2 standards for quality and safety.
Constructed with tough VISTAL plastic housing providing resistance to mechanical stress and high installation torque.

Product Description

SICK IQ10-03BNSKW2S is a block style Inductive Proximity Sensor designed for metal detection in industrial automation applications. This sensor features a compact body with dimensions of 28 mm length, 16 mm width, and 10.3 mm depth, enabling flush mounting in tight spaces.

Equipped with a cable termination, it operates with an NPN output type, delivering a maximum switching current of 200 mA at a supply voltage of 30 V DC. The unshielded sensor offers a detection range up to 3 mm and a high switching frequency of 2 kHz, making it suitable for rapid and precise position sensing.

Constructed with a robust VISTAL plastic housing, the sensor withstands high mechanical stress, installation torque, and harsh environmental conditions with IP67 and IP68 ratings. Operating temperature range from -25°C to 75°C allows reliable performance in varied industrial environments.

Conforming to EN 60947-5-2 standards, this sensor provides consistent performance and long service life, reducing maintenance costs. Typical applications include electronic and solar manufacturing, handling and assembly lines, and general machine manufacturing where precise metal detection is required.

The sensor's block body style enables flexible and secure mounting options. Flush mounting ensures integration in compact assembly setups. The cable terminal and NPN output provide reliable electrical interfacing. High switching frequency supports fast processing in automated systems.

IP67 and IP68 ingress protection ratings safeguard against dust and water ingress, extending durability. The robust plastic housing withstands mechanical and thermal stresses. Wide operating temperature range suits diverse industrial conditions.

Compliance with international standards ensures safety and interoperability. Manufactured in Singapore with stringent quality control. Explore the Electronics & Electricals category on EnvMart for more sensors and automation components to optimize your industrial applications.
