Schneider Electric iC60 Contactor 230V AC Coil, 1-Pole, 90A, Motor Control and Resistive Load, DIN Rail Mount A9C15908
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 77mm |
| Model | A9C15908 |
| Depth | 67mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | iC60 |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw |
| Number of Poles | 1 |
| Standards/Approvals | EN 61095 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 734-9232Brand: Schneider ElectricManufacturers Part No.: A9C15908 |
| Contact Voltage | 230V ac |
| Coil Voltage | 230V ac |
| Contact Current | 90A |
| Operational Current Ie | 15A |
| Contactor Application | Resistive Load |
| Pole and Throw Configuration | 1P |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| Class-2 insulation | continuous safety for operators and unqualified personnel |
| These utilization catagories determine what load the contactors are switching | AC-7a are for slightly inductive loads for household appliances for example mixers and blendersAC-7b are for motor-loads for house hold appliances such as fans and central vacuums |
Key Features
- Designed for motor control and resistive load switching applications.
- Features a 230V AC coil voltage and 1-pole contact configuration.
- Compact size with DIN rail mounting for easy installation.
- Screw terminals with IP20 finger-safe protection for secure connections.
- Rated contact current of 90 amps suitable for industrial loads.
- Built-in auxiliary contacts provide added switching capability.
- Suitable for use in ambient temperatures from -5°C to 55°C.
- Meets EN 61095 standards ensuring safety and reliability.
Product Description
Schneider Electric A9C15908 iC60 Contactor is a robust device designed for power switching in single-phase and three-phase loads with a 230V AC coil voltage. It is tailored for motor control and resistive load applications, delivering dependable performance with a contact current rating of 90 amps. The device is part of the iC60 series, known for its compact size and DIN rail mounting capability, facilitating easy panel integration.
This contactor features screw terminals offering IP20 finger-safe protection, ensuring secure and safe electrical connections. Its operating temperature range of -5°C to 55°C allows for reliable operation across diverse industrial and commercial environments. With compliance to EN 61095 standards, it guarantees safety and quality in demanding applications.
The built-in auxiliary contacts add enhanced switching functionality, making it suitable for various automation needs. The device is designed with class-2 insulation, providing continuous safety for both operators and unqualified personnel. The actuator coil is 100% rated for continuous operation, supporting applications requiring sustained power switching.
Typically used in industrial automation, manufacturing plants, HVAC controls, and electrical distribution systems, this contactor offers versatility and durability. Installation requires spacers between every second contactor on DIN rails to ensure heat dissipation for optimal performance.
Designed for motor control and resistive load switching applications. Features a 230V AC coil voltage and 1-pole contact configuration. Compact size with DIN rail mounting for easy installation. Screw terminals with IP20 finger-safe protection for secure connections.
Rated contact current of 90 amps suitable for industrial loads. Built-in auxiliary contacts provide added switching capability. Suitable for use in ambient temperatures from -5°C to 55°C. Meets EN 61095 standards ensuring safety and reliability.
Manufactured in France, ensuring high quality standards. Class-2 insulation provides continuous safety for operators.
Choose Schneider Electric iC60 Contactors for reliable, compact, and safe power switching solutions in industrial and commercial automation. Explore more Contactors and auxiliary contact models in the Electronics & Electricals Automation & Control Gear category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated contact current of this model is 90 amps, making it suitable for industrial loads.
This contactor features a coil voltage of 230V AC.
It is suitable for use in ambient temperatures ranging from -5°C to 55°C.
It is designed for DIN rail mounting, which facilitates easy installation.
It features screw terminals with IP20 finger-safe protection for secure connections.
This model complies with EN 61095 standards, ensuring safety and reliability.
The dimensions of this unit are 77mm in length, 90mm in width, and 67mm in depth.
It is designed for motor control and resistive load switching applications.
Yes, it includes built-in auxiliary contacts that provide added switching capability.
It features class-2 insulation, which provides continuous safety for operators and unqualified personnel.
The operational current rating for this contactor is 15A.
This contactor is manufactured in France, ensuring adherence to high quality standards.
