Texas Instruments Multiplexer 4 CMOS Triple Logic IC 16-Pin TSSOP CD74HC4053PWR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 5mm |
| Model | CD74HC4053PWR |
| Width | 4.4mm |
| Mount Type | Surface |
| Compatibility | Input CMOS, Output CMOS |
| Output type | CMOS/TTL |
| Series | CDx4HC405x |
| Configuration | Triple |
| Maximum Operating Temperature | 125°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -55°C |
| Operating Voltage | 2 to 6 V |
| Pin Count | 16 |
| Number of Elements per Chip | 4 |
| Maximum Supply Voltage | 6V |
| Logic Family | CMOS |
| Minimum Supply Voltage | 2V |
| Multiplexer/Demultiplexer | Multiplexer, Demultiplexer |
| Maximum On State Resistance | 270Ω |
Key Features
- CMOS logic family providing low power operation.
- Operates over a supply voltage range of 2 V to 6 V.
- Contains 4 elements per chip with triple configuration.
- Surface mount type with compact TSSOP package.
- Maximum operating temperature up to 125°C for robust performance.
- Low maximum on state resistance of 270Ω ensures efficient switching.
- Pin count of 16 with dimensions 5 mm length by 4.4 mm width and 1.15 mm height.
- Compatible with CMOS inputs and outputs as well as TTL logic levels.
Product Description
Texas Instruments CD74HC4053PWR is a 4 CMOS triple multiplexer and demultiplexer logic IC designed for use in advanced electronic circuits requiring efficient signal routing. The device features CMOS technology enabling high-speed operation comparable to LSTTL logic families while maintaining low power consumption. Packaged in a 16-pin TSSOP surface mount form factor, it is well suited for compact PCB designs.
Operating reliably over a voltage range of 2 V to 6 V and temperatures from -55°C to 125°C, this multiplexer supports a wide variety of industrial and commercial applications including signal multiplexing, switching, and demultiplexing in communication, instrumentation, and control systems.
The device includes 4 independent elements arranged in a triple configuration, with low on-state resistance of 270 ohms enhancing switching efficiency. Its compatibility with CMOS and TTL logic levels ensures flexible interfacing in mixed-signal environments.
With precise dimensions of 5 mm length, 4.4 mm width, and 1.15 mm height, this IC optimizes space usage on printed circuit boards. It does not carry specific automotive or industrial certifications but meets standard logic IC performance requirements.
CMOS logic family delivers low power consumption with high-speed operation. Wide operating voltage from 2 V to 6 V supports flexible power supply designs. Surface mount TSSOP package facilitates compact footprint and automated assembly.
Robust temperature range (-55°C to 125°C) for diverse environmental conditions. Low on-state resistance ensures efficient signal switching and minimal losses. Compatible with both CMOS and TTL logic levels for versatile circuit integration.
Suitable for multiplexing and demultiplexing signals in electronic systems. Compact package dimensions enable dense PCB layouts in industrial and consumer electronics. Four elements per chip enable multiple multiplexing operations within one IC.
Ideal for applications in instrumentation, communications, computing, and control equipment. Explore the extensive range of multiplexer and demultiplexer ICs suitable for laboratory, industrial, and electronic design projects at EnvMart.
Explore more products in our Multiplexer/Demultiplexer ICs category.
