Amphenol Industrial signalmate C091 12 Pole Straight M16 Panel Mount DIN Plug 3A 150V T3637001U
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 150V |
| Brand | Amphenol Industrial |
| Orientation | Straight |
| Current | 3A |
| Model | T3637001U |
| IP Rating | IP40 |
| Mount Type | Panel Mount |
| Housing Material | Polymer, Metal |
| Contact Material | Brass |
| Series | signalmate C091 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Pole Format | 12 |
| Contact Plating | Silver |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Mating Type | Screw-On |
| Connector Size | M16 |
| Amphenol C 091 D Series, 12 Pole Din Plug Plug, 3A, 150 V ac/dc IP67Brand | Amphenol Industrial |
Key Features
- This DIN plug features 12 brass contacts with silver plating for enhanced conductivity.
- The housing is constructed from durable polymer and metal materials ensuring mechanical strength.
- Screw-on mating type with metal locking ring complies with DIN EN 60130-9 standards for secure connection.
- The plug supports solder termination and is designed for panel mounting with 3.5 mm panel depth.
- Rated IP40 for protection and operates between -40°C and 85°C suitable for varied environments.
- Its straight orientation simplifies cable routing and installation in control panels.
- Amphenol’s signalmate C091 series provides consistent performance in industrial electronics applications.
- Manufactured in China, this product is UL registered under file number E 63 093 ensuring quality compliance.
Product Description
Amphenol Industrial T3637001U 12 Pole Straight M16 Panel Mount DIN Plug is engineered to provide reliable and secure electrical connections for industrial electronics and control systems. Designed to operate at currents up to 3 amperes and voltages of 150 volts, this connector ensures durability and safety in demanding environments.
The plug features a robust housing made of polymer and metal materials, along with 12 male brass contacts plated in silver for optimal electrical conductivity and corrosion resistance. It incorporates a metal locking ring with screw coupling in accordance with DIN EN 60130-9 / IEC 60130-9 standards, guaranteeing a secure mechanical connection with corresponding connectors.
The panel mount design with a 3.5 mm panel depth allows straightforward installation, while the solder termination ensures dependable contact integrity. Rated with IP40 ingress protection, this plug is suited for challenging industrial and manufacturing conditions, operating reliably in a temperature range from -40°C to 85°C.
The straight orientation facilitates easy cable management in control panels and automation equipment. Its UL registration under file number E 63 093 confirms its compliance with recognized safety benchmarks.
This connector is ideal for use in industrial machinery, automation control, manufacturing equipment, and electrical panels where robust and dependable signal transmission is critical. It supports various applications such as power connectors, panel wiring, and industrial communication interfaces.
This DIN plug features 12 brass contacts with silver plating for enhanced conductivity. The housing is constructed from durable polymer and metal materials ensuring mechanical strength. Screw-on mating type with metal locking ring complies with DIN EN 60130-9 standards for secure connection.
The plug supports solder termination and is designed for panel mounting with 3.5 mm panel depth. Rated IP40 for protection and operates between -40°C and 85°C suitable for varied environments. Its straight orientation simplifies cable routing and installation in control panels.
Amphenol’s signalmate C091 series provides consistent performance in industrial electronics applications. Manufactured in China, this product is UL registered under file number E 63 093 ensuring quality compliance. Explore the comprehensive range of DIN Connectors and industrial electronics at EnvMart to find compatible accessories and components suited to your industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 3 amperes.
It is designed to operate at a voltage of up to 150 volts.
The DIN plug has an IP40 ingress protection rating.
The housing is made from polymer and metal materials, while the contacts are brass with silver plating.
It operates reliably within a temperature range of -40°C to 85°C.
The connection is secured using a screw-on mating type with a metal locking ring, complying with DIN EN 60130-9 standards.
This model supports solder termination for reliable contact integrity.
It is designed for panel mounting with a depth of 3.5 mm.
This connector features 12 male contacts.
The connector has a straight orientation, which simplifies cable routing during installation.
Yes, it is UL registered under file number E 63 093, ensuring compliance with recognized safety standards.
It is suitable for use in industrial machinery, automation control, manufacturing equipment, and electrical panels.
