Schneider Electric LC1D Series Contactor 230V AC Coil, 4-Pole, 18A, 2.5W Power Rating, 2 NO/2 NC Contacts, 690V AC

Schneider Electric LC1D188P7 is a high-quality reversing contactor specifically engineered for automation and electrical control systems. Featuring a 230V AC coil voltage and a 4-pole design, this contactor delivers reliable switching performance for industrial applications.

The device is capable of handling an 18A contact current with a voltage rating of up to 690V AC, making it suitable for controlling resistive loads and motor reversing operations. It includes 2 normally open and 2 normally closed auxiliary contacts, configured as 1 NO/1 NC for flexible control circuit designs.

Designed for convenient DIN rail mounting, the compact contactor measures 45mm in length, 91mm in width, and 99mm in depth, occupying minimal panel space. Screw terminal connections ensure secure and durable wiring, compatible with various cable sizes.

This model supports an operational current (Ie) of 32A and complies with utilization categories AC-1, AC-3, AC-3e, and AC-4, catering to different load types and switching requirements in industrial settings. It operates reliably within a temperature range of -5°C to 60°C, ensuring durability under challenging environmental conditions.

Manufactured to meet international safety and quality standards including CCC, CSA, EAC, IEC, RoHS, and UL, the LC1D188P7 offers peace of mind for demanding industrial applications. Its mechanical construction is robust to withstand vibrations and shocks encountered in industrial environments.

Additional features include an overvoltage category III rating and a rated insulation voltage of 690V, enhancing safety and compliance. The contactor incorporates screw clamp terminals for both power and control circuits, facilitating efficient installation and maintenance.

Produced in Indonesia, this Schneider Electric contactor is designed for sustainability with easy disassembly for recycling and disposal. It is ideal for automation, motor control, industrial machinery, and electrical protection systems. Available to support a broad range of industrial automation needs.

Explore the Schneider Electric product range and automation gear selection on EnvMart for reliable and efficient control solutions. Operates at 230V AC coil voltage with 4 poles and 18A contact current. Includes 2 NO/2 NC auxiliary contacts with 1 NO/1 NC configuration.

Mounts easily on DIN rail with compact size for efficient panel use. Rated for 32A operational current under multiple utilization categories. Supports screw terminal wiring for secure electrical connections. Designed to function in temperatures from -5°C to 60°C.

Meets international standards CCC, CSA, EAC, IEC, RoHS, and UL. Constructed for mechanical robustness and industrial reliability. Manufactured in Indonesia with sustainability-focused design.
