Microchip PIC16F15323-I/P 8 Bit CPU PIC16 Microcontroller 32 MHz 3.5kB FLASH 8-Pin PDIP

Microchip PIC16F15323-I/P is a high-performance 8 Bit CPU PIC16 Microcontroller designed for a broad range of low-power applications in industrial, commercial, and embedded systems. Operating at a maximum clock frequency of 32 MHz, it features 3.5kB FLASH program memory and 256 bits of RAM, enabling efficient processing and versatile program storage.

This microcontroller is housed in an 8-Pin PDIP package with through-hole mounting for straightforward PCB integration. It supports standard communication interfaces such as EUSART, I2C, and SPI, facilitating seamless data exchange in complex system architectures.

The device offers advanced peripherals including 11 channels of 10-bit ADCs for accurate analog-to-digital conversion, a 5-bit Digital-to-Analog Converter (DAC), and two analogue comparators for signal monitoring. These features make it suitable for precision sensor interfacing and control applications.

Designed with energy efficiency in mind, the PIC16F15323-I/P includes eXtreme Low Power (XLP) modes like IDLE and DOZE to extend battery life in portable or remote applications. It operates reliably in extreme temperatures ranging from -40°C to 85°C, ensuring durability in harsh environments.

Additional features include peripheral pin select (PPS), core independent peripherals, complementary waveform generator, and numerically controlled oscillator, enhancing application flexibility. Application areas encompass industrial automation, consumer electronics, and instrumentation.

Features an 8 Bit CPU designed for efficient processing. Includes 3.5kB of FLASH program memory for versatile application code storage. Operates at a maximum clock frequency of 32 MHz for rapid computation. Compact 8-Pin PDIP through-hole mount package ensures easy PCB integration.

Supports communication interfaces including EUSART, I2C, and SPI for flexible data exchange. Offers a RAM size of 256 bits to support runtime data operations. Includes 11 channel 10-bit ADC for precise analog signal conversion.

Equipped with 5-bit DAC and 2 analogue comparators for analog output and signal comparison. Operates over an extended temperature range from -40°C to 85°C for robust industrial performance. Low power consumption with eXtreme Low Power modes (IDLE and DOZE) for energy efficiency.

This microcontroller is RoHS compliant, aligning with stringent environmental regulations. Its balance of capability, power efficiency, and compact packaging makes it ideal for deployment in embedded designs requiring robust performance and longevity.
