Lapp Unitronic LiHCH Series Data Cable 8 Pairs 0.14 mm² 50 m Pebble Grey Sheath Low Smoke Zero Halogen 0038308
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 250V |
| Brand | Lapp |
| CROSS SECTIONAL AREA | 0.14 mm² |
| Model | 0038308 |
| Cable Length | 50m |
| Series | Unitronic LiHCH |
| Outside diameter | 8.4mm |
| Maximum Operating Temperature | 80°C |
| Conductor Material | Bare Copper |
| Minimum Operating Temperature | -40°C |
| Jacket Material | Low Smoke Zero Halogen |
| Standards/Approvals | EU-Directive 2014/35/EU (Low Voltage Directive) and to EU-Directive 2011/65/EU (RoHS, Restriction of the use of certain hazardous substances) |
| Jacket Colour | Pebble Grey |
| Fire Behaviour | Flame Retardant acc. to IEC 60332-1-2 |
| Screened/Unscreened | Screened |
| Conductor Type | Stranded |
| Number of Pairs | 8 |
| • Operating temperature range of with occasional flexing | -5°C to +70°C |
| • Operating temperature range in fixed installations | -30°C to +80°C |
Key Features
- The cable features a low smoke zero halogen (LSZH) jacket for enhanced safety in public spaces.
- It offers flame retardant properties according to IEC 60332-1-2 standards.
- The stranded bare copper conductors ensure reliable signal transmission.
- The sheathed cable is screened to minimize electrical interference.
- The pebble grey sheath color aids in easy identification.
- Designed to operate within -30°C to +80°C in fixed installations.
- The cable is compliant with EU-Directive 2014/35/EU and RoHS directives.
- Ideal for data processing, measurement, control engineering, and safety related systems.
Product Description
Lapp 0038308 Unitronic LiHCH Series Data Cable is an industrial-grade screened twisted pair cable designed for low frequency data transmission applications. It features 8 pairs of 0.14 mm² stranded bare copper conductors with polyolefin-based insulation to ensure low capacitance. The cable has a pebble grey colored, flame-retardant, low smoke zero halogen (LSZH) outer sheath, which supports safety in environments where public safety and property protection are critical.
The cable construction includes a braided screening layer to effectively minimize electrical interference, making it highly suitable for sensitive instrumentation, control engineering, and computer systems. It can operate in fixed installations within a temperature range of -30°C to +80°C and supports occasional flexing between -5°C to +70°C.
The product complies fully with EU Low Voltage Directive 2014/35/EU and the RoHS directive 2011/65/EU restricting hazardous substances. It meets flame retardancy as per IEC 60332-1-2 standards, ensuring enhanced fire safety performance.
The Lapp Unitronic LiHCH cable is specifically developed to serve critical public environments such as public buildings, transport systems, and safety-related networks where low smoke emission and halogen-free attributes are mandatory.
Low capacitance cable insulation enhances data transmission performance. Screened braid provides excellent electrical interference protection. Halogen free, low smoke jacket reduces harmful emissions during fire. Compliant with EU safety and environmental directives.
Wide operating temperature range suitable for diverse environments. Robust bare copper conductors ensure communication reliability. Pebble grey sheath for easy identification in cable management. Ideal for office equipment, measurement, control, and safety systems.
Compatible with Lapp EMC cable glands enhancing installation integrity. Set includes one 50-meter reel of Lapp Unitronic LiHCH screened twisted pair Data Cable. Explore more high-performance electrical cables in the EnvMart catalogue for industrial, commercial, and lab applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for the Lapp Unitronic LiHCH data cable is 80°C.
This model comes with a cable length of 50 meters.
The cable features 8 pairs of conductors.
It uses stranded bare copper conductors for reliable signal transmission.
The outside diameter of the cable is 8.4 mm.
The cable meets flame retardancy as per IEC 60332-1-2 standards.
The minimum operating temperature is -40°C.
Yes, it complies with EU-Directive 2014/35/EU (Low Voltage Directive) and EU-Directive 2011/65/EU (RoHS).
The cable features polyolefin-based insulation to ensure low capacitance.
The jacket is made from Low Smoke Zero Halogen (LSZH) material.
It is ideal for data processing, measurement, control engineering, and safety-related systems.
Yes, it is designed for fixed installations and operates within a temperature range of -30°C to +80°C.
