Lapp Unitronic LiHCH Series Data Cable 4 Pairs 0.25 mm² 50 m Pebble Grey Sheath Low Smoke Zero Halogen 0038404

Free Delivery in India | Lowest Global Shipping Charges

Lapp Unitronic LiHCH Series Data Cable 4 Pairs 0.25 mm² 50 m Pebble Grey Sheath Low Smoke Zero Halogen 0038404

Name: Lapp Unitronic LiHCH Series Data Cable 4 Pairs 0.25 mm² 50 m Pebble Grey Sheath Low Smoke Zero Halogen 0038404
Brand: Lapp
SKU: 315608
Price: 285.72 USD
Availability: InStock



Category Data Cable Brand Lapp Condition New

Specifications

Country of Origin	Germany
Voltage	250V
Brand	Lapp
CROSS SECTIONAL AREA	0.25 mm²
Model	0038404
Cable Length	50m
Series	Unitronic LiHCH
Outside diameter	7.8mm
Maximum Operating Temperature	80°C
Conductor Material	Bare Copper
Minimum Operating Temperature	-40°C
Jacket Material	Low Smoke Zero Halogen
Standards/Approvals	EU-Directive 2014/35/EU (Low Voltage Directive) and to EU-Directive 2011/65/EU (RoHS, Restriction of the use of certain hazardous substances)
Jacket Colour	Pebble Grey
Screened/Unscreened	Screened
Conductor Type	Stranded
Number of Pairs	4
• Operating temperature range of with occasional flexing	-5°C to +70°C
• Operating temperature range in fixed installations	-30°C to +80°C

Key Features

The cable has 4 pairs of stranded bare copper conductors with a cross-sectional area of 0.25 mm².
The pebble grey jacket is made of halogen-free, low smoke zero halogen material ensuring flame retardancy.
It has an outside diameter of 7.8 mm and is rated for 250 V operation.
Operating temperature ranges from -40°C minimum to 80°C maximum, with flexibility down to -5°C in occasional flexing.
The cable is screened to minimize electrical interference and complies with EU low voltage and RoHS directives.
Flame retardant according to IEC 60332-1-2 standards.
Ideal for data processing, measurement, control engineering, and safety-related systems.
Suited for applications in public buildings, public transport systems, office equipment, and instrumentation systems.

Product Description

Lapp 0038404 Unitronic LiHCH Series Data Cable is a high-quality screened twisted pair (TP) cable featuring 4 pairs of stranded bare copper conductors with a cross-sectional area of 0.25 mm² and a length of 50 meters. The cable comes with a pebble grey outer sheath made from low smoke zero halogen (LSZH) material, providing excellent flame retardancy and minimal smoke emission in case of fire. It is designed to operate at voltages up to 250 V with temperature ratings suitable for both fixed installations and applications requiring occasional flexing.

This cable is engineered to meet rigorous EU standards including the Low Voltage Directive 2014/35/EU and RoHS Directive 2011/65/EU, ensuring safe usage and environmental compliance. The cable construction includes a halogen-free core insulation and a braided screening layer that effectively minimizes electrical interference, making it suitable for sensitive signal and data transmission.

Its operating temperature range supports from -40°C up to 80°C in fixed installations and -5°C to +70°C under occasional flexing conditions, providing versatile application possibilities in various industrial and commercial environments.

Common use cases include data processing, measurement and control engineering, safety related systems, computer systems, instrumentation, and office equipment where public safety and the protection of sensitive property are vital. Its LSZH properties make it particularly suitable for public spaces such as transport systems and public buildings where low smoke and non-toxic emissions are critical.

The cable features low capacitance due to its polyolefin-based insulation. The overall braid provides excellent shielding against electrical interference. Halogen-free and low smoke characteristics enhance fire safety. Flame retardant according to IEC 60332-1-2 standards.

Designed for industrial, laboratory, construction, and commercial applications requiring reliable data transmission. Package contains one reel of 50 meters of the described data cable. Explore advanced Data Cable solutions in EnvMart's Electronics & Electricals category for superior performance and compliance.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum operating temperature of this model is 80°C.

This data cable has a length of 50 meters.

It features 4 pairs of stranded bare copper conductors with a cross-sectional area of 0.25 mm².

The outside diameter of this unit is 7.8 mm.

The jacket is made of low smoke zero halogen (LSZH) material, ensuring flame retardancy and minimal smoke emission.

The minimum operating temperature with occasional flexing is -5°C.

Yes, it complies with EU directives including the Low Voltage Directive 2014/35/EU and the RoHS Directive 2011/65/EU.

It is ideal for data processing, measurement, control engineering, and safety-related systems, particularly in public buildings and transport systems.

This model is rated for operation at 250 V.

The cable is screened, which effectively minimizes electrical interference, making it suitable for sensitive signal and data transmission.

The operating temperature range for fixed installations is from -40°C to 80°C.

The country of origin for this model is Germany.
